FORM TREATMENT
Anchor Slot
Used where masonry veneer is to be placed over
concrete. Dovetail slot is accurately formed of 24 gauge
galvanized steel filled with foam. The foam filler prevents
grout from filling the slot. For application pre drill slot and
attach to form work on 12" centers. Use caution not to
allow dovetail to spread or collapse. Once forms are
stripped, dovetail anchors are keyed into the slot.
Chamfer - PVC Flexible
Chamfer Strip makes exposed outside corners of
columns, beams and joists better looking and more
durable. Nearly perfect corners are possible on columns
as small as four inches. Reusable PVC works like wood
but lasts 4 to 10 times longer. For maximum life chamfer
strip should be applied with staples. 10 lf lengths.
Steel Chamfer
Used with steel forms to produce smooth straight
corners with multiple reuses.
No.
Description
Wt/Pc (lbs)
AA 24DTG 24 Gauge x 10' lengths
3.8
Also available in other gauges and stainless.
No.
Size
Wt/Pc (lbs)
SY 42168
1/2"x10'
4.4
SY 42169
3/4"x10'
11.2
SY 42170
1"x10'
17.5
No.
Description
Wt/Pc (lbs)
GS 602 1/2" Radius w/Tail
1.2
GS 603 3/4" Radius w/Tail
2.3
GS 604 1" Radius w/Tail
3.8
GS 611 1/2" w/Tail
1.2
GS 612 3/4" w/Tail
2.3
GS 613 1" w/Tail
3.8
GS 621 1/2" No Tail
1.0
GS 622 3/4" No Tail
2.0
GS 623 1" No Tail
3.5
Standard Chamfer Dimensions
Size A Dimension B Dimension
1/2"
1/2"
23/32"
3/4"
3/4"
1-1/16"
1"
1"
1-13/32"
«--------------B------------»
«----------A----------»
(See Pages 233-234 for more Chamfers)
With Tail
No Tail
