FORM TREATMENT
Expanding Foam Sealant
Description:
A single component,
moisture-cure, polyurethane
foam sealant with a (H) CFC free
propellant designed to fill gaps,
cracks, etc., and used to stop air
infiltration around door and window
frames and pipe penetrations.
Application:
Fill the lowest part of the
cavity first. When using Expanding
Sealant, fill only 40% with foam since
formula expands approximately
2-1/2 times. Temperature of the
surface to be foamed should be
40-95° F. Optimal can temperature
is 70-80°F. Expanding Sealant will
withstand continuous temperatures
up to 195° F.
Specifications
:
68° F
Color
:
Yellowish
Expanded Volume:
Free Rise
Density
:
1.6 lbs./ft³
Tack Free
:
10 min
Cuttable
:
45 min
R Factor
(ASTM G-518): 3.8-4.5
Coverage:
Can Size:
12 oz. can yield = 0.5 ft³
Bead Size:
3/8" = 12 oz. = 275 linear ft.
Step Liners
With Step Liners, shaping overhangs becomes a snap. Use spray adhesive and/or roofing
tacks to fasten Step Liners to the inside of formwork. Radius steps may be set using bender
board or masonite siding instead of rigid wooden forms. Break-away slots allow for 3 riser
heights. Step Liners may be stripped and finished much earlier than conventional forms
because it acts as a foam cushion against concrete.Use MASCO Bio Release Waterbased
form release agent on form surface.
No.
Size
Wt (lbs) Qty/Ctn
FL QF 12oz
1.1
12
Intermediate
Riser Heights
7.5
6.5
5.5
Ris r
i hts
t rmediate
Intermediate
Sandstone
1.125 R.
1.5625 R.
3.375 D.
.
FAMOWOOD
®
Description:
FAMOWOOD® Instant
Wood Repair is a 2-component
polyurethane (2:1 ratio by volume)
resin system that comes in a single
cartridge. It is less than 1% VOC and
contains no solvents. It is designed for
wood restoration and repair defects
such as holes, cracks and gouges, for
virtually any job large or small. Can
be applied on to flat, sloped and/or
vertical surfaces without running,
dripping or shrinking.
FAMOWOOD® can be troweled
for precise coverage to mirror the
original surface. Product can be
applied using hand-held cartridge
dispensing applicators (top loading
caulk gun for 6.1 fl oz./180mL) for
small applications, or using metering
equipment for larger industrial
applications.
Application:
Can be used for repair
and restoration on log homes,
trim work, base & crown moldings,
cabinet restoration, and Marine
- boat docks and pilings. Fills the
voids for window replacement, deck
repairs, architectural timber repairs
and dry rot wood repairs.
Specifications:
70° F
Mix Ratio (volume):
2A:1B
Pot Life:
2 min
Cure Time:
Initial:
10 min
Final:
60 min
Viscosity:
Gel
Concrete Adhesion:
500 psi
(ASTM D-4541)
Shore "D" Hardness:
60
(ASTM D-2240)
Coverage:
1 each 6.1 fl. oz. cartridge
yields approximately 11 in
3
of gel.
No.
Size
Wt (lbs) Qty/Ctn
WV FW 6.1oz
1.1
12
No.
Description
Length Lf/Ctn Wt/Ctn (lbs)
STG 2STP40 Intermediate
4 ft.
40
6.0
STG 17STP40 Sandstone
4 ft.
28
6.0
Other sizes available on request.
SEALANT/REPAIR/LINERS
