SLAB/HORIZONTAL
SCREEDS
K-FORM
K-FORM PVC Screed Railing provides a high
quality, economical, efficient and environmentally
friendly alternative to steel forms. K-FORM is made
from recycled materials, is lightweight, durable
and does not require removal after concrete
pouring. It is easily cut to length on site and has
pre-drilled holes in the vertical face for installing
dowel bars and in the base for mortar anchoring.
It is an ideal choice for isolation joints. Patented
design comes with a built-in expansion joint,
click-together design, removable Top Strip for joint
sealing and end clips for joining. The pouring of
floor slabs has never been so easy. The lightweight
system can be set up four times more quickly
than traditional steel formwork. No special tool or
diamond cutting required.
No.
Description
Dimensions
For Slabs
Wt (lbs)
PS K35
K35
2" x 8' w/void cap 2" – 2½"
6.50
-
K35 plus 1" riser
3" – 4"
PS K85
K85
4" x 8' w/void cap 4" – 5"
7.00
-
K85 plus 1" riser
5" – 6"
PS K135 K135
6" x 8' w/void cap 6" – 7"
7.50
-
K135 plus 1" riser
7" – 8"
-
K135 plus 2 x 1" riser
8" – 9"
Accessories
PS KCROSS Cross Top T-Strip can be used with K35, K85 & K135
1.00
PS KEXT
Extension Cap
1" x 8'
1.00
If used as above, the maximum bed up height is up to 1" and 3/8"
Eight holes drilled
at 32" intervals
(four per side) to
aid anchoring
with mortar.
MORE THAN
80%
LIGHTER THAN
STEEL FORMS
K135
7/8" holes
pre-drilled
at 11¾"
centers for
dowel bars.
Cross Top T-Strip
90° CORNERS
T-JUNCTIONS
CROSSINGS
2"
1"
8'
1" Extension Strip
Standard K-FORM
Removable top strip
