MASONS SUPPLY COMPANY
Oregon (800) 537-3407 ♦ Washington (800) 537-6216
Clackamas | Eugene | West Eugene | Hillsboro | Medford | Portland | Salem | Wilsonville | Ridgefield | Seattle | Tacoma | Woodinville
M A S C O . N E T
SLAB/HORIZONTAL
SCREEDS
Pads
Used in conjunction with the tapped screed post for
screeding over waterproof membrane and wood and
steel decking. Cast aluminum with 1/2" NC diameter
male threads.
Posts
Screw Point Screed Post
for wood forms or decking.
3/4" round stock. Pre-drill a 1/4" hole for lag screws.
Tapped Screed Posts
1/2" tapped post fits threaded
sections of screed pad when screeding over
waterproof membrane.
Plastic Key Way
This flexible polyethylene strip is nailed to a form or header
before pouring. When stripped out later, a keyway is
left in the concrete. Used to lock multiple on-grade
slabs together in tilt-up buildings, insulated floors, curbs,
driveways and wherever specified. Will not split chip or
crack in any temperature. 2-1/8" recommended for 6"
thick slabs. 3-1/2" recommended for 12" thick slabs.
Adjustable Chair
The Adjustable Screed Chair is a multipurpose chair for
level decks and accurate depression forms and comes
with a base, adjustable ring, and 2 x 4 saddle. Simply
attach the base to the form and place 3/4" PVC Pipe
(not included) into the base. Then place the saddle,
with the adjusting ring on top of the pipe and twist the
saddle to the required elevation. Designed to allow up
to 1" adjustment. 100 pieces per carton.
THREADING
CAN BE ADJUSTED
TO MAX. OF 1"
¾" PVC ADJUSTABLE
(NOT INCLUDED)
NAIL OR
SCREW
STAPLE
No.
Size
Offset
Wt (lbs) Qty/Ctn
CFA PK218 2-1/8" x 10'
3/4"
1.2
500 Ft
CFA PK312 3-1/2" x 10'
1-1/2"
2.2
400 Ft
No.
Size
Wt (lbs)
CT 10SP
10"
1.25
CT 12SP
12"
1.50
CT 16SP
16"
2.00
CT 18SP
18"
2.25
CT 24SP
24"
3.00
No.
Size
Wt (lbs)
CT 10TP
10"
1.25
CT 12TP
12"
1.50
CT 16TP
16"
2.00
CT 18TP
18"
2.25
CT 24TP
24"
3.00
No.
Description Wt (lbs)
AZ PAS400
Assembly
0.17
No.
Wt (lbs)
CT SP
0.16
