SLAB/HORIZONTAL
REINFORCING
Rebar
Reinforcing Steel is available in straight 20' lengths.
No.
Grade
Size
CT 3R
60
3/8" x 20'
CT 4R
60
1/2" x 20'
CT 4R4
40
1/2" x 20'
CT 5R
60
5/8" x 20'
CT 6R
60
3/4" x 20'
Cut lengths are available on request.
Size
Diameter
Gage
W 1.4
.134"
10 Gage
W 1.7
.147"
9 Gage
W 2.1
.164"
8 Gage
W 2.5
.178"
7 Gage
W 2.9
.192"
6 Gage
W 4.0
.226"
4 Gage
W 5.4
.262"
2 Gage
W 6.2
.281"
1 Gage
#3
0.376 0.375
0.11
1.178
#4
0.668 0.500
0.20
1.571
#5
1.043 0.625
0.31
1.963
#6
1.502 0.750
0.44
2.356
#7
2.044 0.875
0.60
2.749
#8
2.670 1.000
0.79
3.142
#9
3.400 1.128
1.00
3.544
#10
4.303 1.270
1.27
3.99
#11
5.313 1.410
1.56
4.43
#14
7.650 1.693
2.25
5.32
#18 13.600 2.257
4.00
7.09
ASTM STANDARD REINFORCING BARS
BAR SIZE
DESIGNATION
WEIGHT
POUNDS
PER FOOT
NOMINAL DIMENSIONS - ROUND
SECTIONS
DIAMETER
INCHES
CROSS
SECTIONAL
AREA-SQ.
INCHES
PERIMETER
INCHES
Mesh
Produced of heavy gauge 6" x 6" square mesh. Provides effective reinforcement for concrete floors,
walks, water tanks and pools. 10 gauge wire. Meets ASTM A-185 specifications.
No.
Spacing Gauge New
Wire Size Width/Length Sheets Per
Sub
Sheets/
Bundle
SQ FT
Wt (lbs)
Rolls
W REINF5
6 x 6
10/10
1.4
5' x 150'
-
-
750/Roll
154.00/Roll
W REINF7.5
6 x 6
10/10
1.4
7.5' x 200'
-
-
1,500/Roll
315.00/Roll
Sheets
W REINFMAT
6 x 6
10/10
1.4
4' x 7'
25
100
28/Sheet
5.88/Sheet
W REINFMAT20
6 x 6
10/10
1.4
7.5' x 20'
25
100
150/Sheet
31.50/Sheet
MECHANICAL REQUIREMENTS FOR
STANDARD ASTM DEFORMED REINFORCING BARS
Type of Steel
and ASTM
Designation
Bar Nos.
Range Grade
1
Minimum
2
Yield
Strength, psi
Minimum
Tensile
Strength, psi
Billet-Steel
A615
3-6
40
40,000
70,000
3-11, 14, 18 60
60,000
90,000
6-11, 14, 18 75
75,000
100,000
Low-Alloy
Steel A706
3-11, 14, 18 60
60,000
4
80,000
5
1
Minimum yield designation (KSI).
2
Yield point or yield strength. See ASTM specifications.
4
Maximum yield strength 78,000 psi (ASTM A706 only).
5
Tensile Strength shall not be less than 1.25 times the actual yield strength. (ASTM A706 only).
