MASONS SUPPLY COMPANY
Oregon (800) 537-3407 ♦ Washington (800) 537-6216
Clackamas | Eugene | West Eugene | Hillsboro | Medford | Portland | Salem | Wilsonville | Ridgefield | Seattle | Tacoma | Woodinville
M A S C O . N E T
6"
16"
9"
SLAB/HORIZONTAL
Fiber
A preformed, non-extruding resilient filler, saturated with
high quality bituminous materials having preserving
characteristics. The material is strong, but lightweight,
cuts and handles easily, resists breakage. It will not
extrude from the joint under normal compression and
service temperatures and does not become brittle in cold
weather. Useful in all types of concrete construction in
both interior and exterior applications. 100 lf per bundle.
Conforms to:
ASTM D 1751
HHF- 341 F Type 1
AASHTO M 213
CRD C 508
FAA P-610-2.7
Full Sheets
Curb Cuts
Curb and Gutter Sections are fabricated on special order.
The two general types are shown here and supplied in
fiber joint from sheet stock in 1/2" thickness.
Removable Joint Cap
Eliminates joint cleanup, saving hours of labor.
Eliminates the need for joint backer rod and most
of the handwork normally spent forming expansion
joints to be caulked and sealed in concrete slabs or
any horizontal or vertical masonry. Manufactured
with strong, high impact polystyrene (HIPS). The strip
slides over the top of the expansion board just prior
to concrete placement. The lower section of the
cap is keyed in the concrete and the top section
strips to create a reservoir for sealants. Easily cut with
a hand or power saw. Easily stripped by inserting a
screwdriver and pulling up. Provides sharp, clean
professional grooving available in several sizes to
accommodate most applications. 500 lf per carton.
No.
Size
Wt/Clf (lbs)
EX 382
3/8" x 2" x 10'
13.0
EX 122
1/2" x 2" x 10'
15.0
EX 383
3/8" x 3" x 10'
19.0
EX 123
1/2" x 3" x 10'
22.0
EX 38312
3/8" x 3-1/2" x 10'
22.0
EX 12312
1/2" x 3-1/2" x 10'
25.0
EX 384
3/8" x 4" x 10'
25.5
EX 124
1/2" x 4" x 10'
30.0
EX 38512
3/8" x 5-1/2" x 10'
38.0
EX 12512
1/2" x 5-1/2" x 10'
44.0
EX 386
3/8" x 6" x 10'
38.0
EX 126
1/2" x 6" x 10'
44.0
Other sizes available upon request.
No.
Size
Wt (lbs) Qty/Plt
EX 384’10 3/8" x 4’ x 10'
38.0
100
EX 124’10 1/2" x 4’ x 10'
50.0
80
EX 344’10 3/4" x 4’ x 10'
75.0
50
EX 14’10 1" x 4’ x 10'
100.0
40
No.
Size
Wt (lbs)
EX CC
6" x 9" x 16"
1.0
EX CG
6" x 12" x 24"
1.65
No.
Size
Wt/Pc (lbs)
EX JC38
3/8" x 1/2"
0.42
EX JC12
1/2" x 1/2"
0.44
EX JC34
3/4" x 1/2"
0.65
EX JC1
1" x 1/2"
0.84
EXPANSION JOINT
Cut Sizes
6"
12"
24"
6"
