DOWELING
SLAB/HORIZONTAL
Plate Dowel Basket
Our plate dowel systems are used in “Strategic
Reinforcement” design that helps you achieve
superior load transfer while optimizing the amount
of steel in concrete slabs-on-ground. Our plate
dowel baskets are a smarter, more efficient way
to deliver the durable, maintenance-free floors
your customers expect. Plate dowel basket
assemblies allow you to optimize the amount
of steel in a project, limit your liability by using
the latest ACI 302.IR-04 guidelines, and deliver
a cost-effective slab-on-ground. Reduces man
hours for installation. Allows subgrade leveling
after installation to prevent rutting. Construction
tolerance allow for misalignment without causing
restraint in the panels. Eliminates obstacles for the
laser screed. Can be installed during pouring. Fully
wielded assemblies, offering stable dowel support
during installation.
Dowel Baskets
Wire suspension basket for poured in place Dowel
Baskets. Dowels are supplied in basket, and can
be supplied epoxy coated, painted, or plain. Use
as an installation system for concrete slab dowels.
Manufactured for tilt-up, highway, and airport
runway slabs. Provides a more accurate method
of installing steel expansion and contraction
joints. Dowels are more precisely centered in
slab, making it easier for the contractor to adhere
to stringent engineering specifications. Keeps
the dowels from being installed at an angle,
which will insure proper movement of the slab.
Gives the contractor a huge labor savings, over
conventional forming methods. Dramatically
cuts slab construction time. Fabricated for 3/4",
1",1-1/4" and 1-1/2" diameter dowels as required.
To order specify type (expansion or contraction),
dowel diameter centers, paving thickness and
basket length. Made to meet federal, state, city
and airport specifications.
DOWEL BARS ARE ALTERNATELY
WELDED TO ALLOW MOVEMENT
WITHIN THE PAVEMENT
BONDBREAKER CAN BE
APPLIED DURING
MANUFACTURING TO AID
THE MOVEMENT OF THE
DOWEL ONCE EMBEDDED
IN THE PAVEMENT
DOWELS CAN BE PLAIN,
PAINTED, EPOXY COATED OR
STAINLESS STEEL
Pieces or
lineal Feet
Slab or
Lane Width
Dowel
Diameter
Dowel
Length
Finish
Dowel
Centers
Dowels
per Unit
Slab or
Paving
Thickness
Billable
Length*
WORKSHEET/ORDER INFORMATION
* Billable Length = Number of Dowels x Center
