EXPANSION JOINT
SLAB/HORIZONTAL
Benderboard
Easily shapes decorative and curved walkways, patios, pools, and spas. Leaves a clean, smooth surface without pretreating.
Reusable and has no product shrink during shipping, handling, or use, resulting in long-term cost savings. Easy to cut and form using
standard wood working tools. 5/16" thickness bends into tight 1' radius curves or 2' diameter circles without cracking, splitting, or
breaking. Flexible in any temperature and will not absorb moisture.
Flexible Foam
Flexible Foam Expansion Joint Filler is composed of a unique synthetic foam of isomeric
polymers in a very small, closed-cell structure. Gray in color, lightweight, flexible, highly
resilient material offering recovery qualities of over 99%. The compact, closed-cell
structure will absorb almost no water. Flexible Foam Expansion Joint Filler provides
an excellent joint filler and back-up material for use in either horizontal or vertical
applications where expansion and contraction movements must be accommodated.
It is compatible with all currently popular cold-applied sealants,and hot-pour joint
sealing compounds. It is lightweight and easy to cut or form in the field without waste.
Conforms To:
ASTM D5249 TYPE II, ASTM D1752 Section 5.1 through 5.4 with the compression
requirement modified to 10psi minimum and 25 psi maximum.
Foam Joint Filler
Foam Expansion Joint Filler is a tough, flexible, lightweight filler with a long life
expectancy. It is designed to replace brittle asphalt impregnated fillers. It provides a
convenient removable portion that ensures a uniform sealable void in the joint. Prior to
sealing or caulking, the removable strip can be easily extracted leaving a trim clean
joint. Can be used in pool decks, bridge construction, concrete gutters, suspended
walkways, concrete forms, etc.
TPER Expansion Board Cap Seal
A one step complete concrete joint system with a
simple installation. This EB Cap System integrates the
waterstop, forming system, expansion board, joint
seal and load transfer units into a single structure.
Just stake down the board, set your screed
elevation and that's it. No stripping forms and no
messy sealants. Lower labor and installation costs.
No.
Size
Pcs/Bndl
Wt/Lf (lbs)
CT BB1 5/16" x 3-7/16" x 16'
10
.54
CT BB2 5/8" x 3-7/16" x 16'
5
1.08
CT BB4 5/16" x 5-3/8" x 16'
5
.833
No.
Size
Wt (lbs)
WR 124' 10C 1/2" x 4' x 10'
2.4
Other sizes available upon request.
No.
Size
Wt (lbs)
WR 12350DF 1/2" x 3" x 50'
1.40
WR 12450DF 1/2" x 4" x 50'
1.50
No.
Size
Wt/Ctn (lbs)
GS EB637 1/2" x 3"
GS EB638 3/4" x 3"
STANDARD EB CAP
PROFILES
EB638
EB637
1-1/8"
2-7/16"
3"
1/2"
1-1/2"
1/8"
1-3/8"
2-7/16"
3"
1-1/2"
1/8"
3/4"
