POUR IN PLACE
Strap Anchors
Strap Anchors are made of 12 gauge galvanized steel. Meets specifications
for a variety of wood-to-concrete or applications including seismic
anchorage for concrete walls-to-floor details. For anchor down use, the SSAD
series has a 1 piece design, no separate anchors are required. Supplied with
zinc plated finish.
Column Bases
Accommodate heavy column bases and rough sawn posts
or heavy duty fence construction where high structural values
and durable performance are part of the specifications.
Anchors should set in position before pouring concrete.
Erection nail holes are provided to speed up installation.
Supplied with painted black finish.
Post Holders
For use with a variety of dimensional lumber and composite wood
sizes. Low cost post base for patios, carports, breezeways and
porches. Use all specified fasteners. Optional holes may be used
to temporarily secure members while drilling and bolting. Supplied
with painted black finish.
Hold Downs
Designed to be installed at the edge of concrete forms. Tests
determined the pullout strength with one horizontal #4 rebar in
the shear cone. Install before pouring concrete by nailing to the
form. Installation holes allow nailing to the form, resulting in deeper
embedment.Supplied with zinc plated finish.
CB
TYPICAL CB
INSTALLATION
No.
Description
Simp EQ KC EQ USP EQ Wt (lbs) Qty/Ctn
CT SSAD10 10" x 12 ga.
STHD10
SSAD10 STAD10 3.16
10
CT SSAD10RJ 10" x 12 ga. Rim Joist STHD10RJ SSAD10RJ STAD10RJ 4.30
10
CT SSAD14 13" x 12 ga.
STHD14
SSAD14 STAD14 4.40
10
CT SSAD14RJ 13" x 12 ga. Rim Joist STHD14RJ SSAD14RJ STAD14RJ 5.00
10
No.
Description Simp EQ KC EQ USP EQ Wt (lbs)
CT KHPAHD22 35" x 10 ga. HPAHD22 HSA3522 HPAHD22 2.5
No.
Description Simp EQ KC EQ ESP EQ Wt (lbs)
CT 44CB 4" x 4"
CB44
HA44
KCB44 4.5
CT 46CB 4" x 6"
CB46
HA46
KCB46 6.6
CT 66CB 6" x 6"
CB66
HA66
KCB66 8.1
No.
Description Simp EQ KC EQ USP EQ Wt (lbs)
CT 448PH 4" x 4" x 8"
EPB44
EA44
EPB4408 1.6
CT 4412PH 4" x 4" x 12" EPB44-12 EA44-12 EPB4412 2.1
CT 4612PH 4" x 6" x 12" EPB46-12 EA46-12 EPB4612 2.7
CT 6612PH 6" x 6" x 12" EPB66
EA66
EPB6612 3.1
NAIL TO
FORM BOARD
HOLD DOWNS
