VERTICAL FORMING SYSTEMS
MF 240 CLIMBING FORMWORK
MF TRAVELING UNITS
The main operating deck platform is 8' wide for
safe and convenient formwork operations.
The formwork can roll back 2'-6" for easy
cleaning of the formwork and for working on
the reinforcement.
MF 240 CLIMBING FORMWORK
Pressure spindles are available to
enable the MF 240 climbing formwork
to adjust to structures with an angle of
inclination that changes for each lift.
When the structure's angle
of inclination is constant,
pressure struts keep the
formwork at exactly the right
angle up to
± 15°
when using
the vertical profile MF 160.
On structures with vertical
walls, the MF 240 climbing
bracket permits pouring
sections up to 20' high.
ADJUSTABLE ANGLE OF INCLINATION
MF CLIMBING BRACKETS
Combines with all DOKA wall formwork systems.
High load-bearing capacity 11,250 lbs. per
climbing bracket.
Accessories available to accomodate an
angle of inclination ± 15° from vertical.
Enables climbing formwork to pass concrete
lips projecting up to 9-¾".
WORKING PLATFORM BRACKETS
Modular principle for versatility:
These brackets can be used as pouring,
intermediate and suspension platform
brackets.
1
2
3
