VERTICAL FORMING SYSTEMS
Ply Clip
Steel Clips for quick, easy installation between plywood
panel joints. Allows panels to be stacked easier and faster
before floating waler and stiffback bracket are installed.
No.
Size Wt (lbs)
CT 34PC
3/4"
.40
Guardrail Post
Attaches to a scaffold bracket.
1 post per bracket.
No.
Wt (lbs)
GT 78112 6.0
The vertical 2 x 4 stiffback must always extend from a
solid base and never use a short piece of 2x4 under the
scaffold bracket. Never attach the scaffold bracket to
the top row of CamLock Brackets and Form Ties. A 2x4
Stiffback Cam must always be attached to the CamLock
Bracket directly above the Scaffold Bracket. A second
2x4 Stiffback Cam must be attached directly below the
Scaffold Bracket. On all walls, scaffold brackets
must be
spaced within 6'x0". 42" guard rail with toe plate, mid tail
and top rail must be used.
CAM-LOCK
HANDRAIL POST
CAM-LOCK
SCAFFOLD
BRACKET
Scaffold Bracket Attachment
CAMLOCK SYSTEM
