VERTICAL FORMING SYSTEMS
Liner Clamp
Designed for use with a single 2x4 strongback for
vertical form alignment, this liner clamp can be
installed after erection of the forms and is not limited
by form-tie spacing. Sturdy, galvanized construction
reduces maintenance and replacement, and speedy
installation reduces forming costs. Strongbacks are
used to align and not to strengthen forms. They are
normally used on one side only, spaced 6' horizontally.
Liner clamps should attach the strongback to every
other single waler.
Waler Bracket
Unsafe toenail connections can be eliminated and
waler lumber saved by using this bracket. Fasten to
studs with double head nails, insert walers and secure
with Steel Wedge. Normal spacing 4' on center.
Designed for double 2 x 4 or 2 x 6 strongbacks, used
with a heavy duty snaptie wedge. 25/carton.
Steel Wedge
The steel tie holder is fabricated from high carbon
steel and heat treated for added strength. Easily
installed and removed; will not turn or fall off.
50 pieces/carton.
Panel Clip
A thin, strong clip used primarily for adding extra
height to form panels. A common use of the Panel
Clip is as an aid to setting standard narrow filler
panels horizontally on the top of a wall of form panels.
Standard wall ties can be used to tie the wall at the
joint between the fillers and the normal wall panels. 50
pieces per carton.
No.
Wt (lbs)
CFA LC 1.1
No.
Wt (lbs)
CFA SW5 0.88
No.
Size
Wt (lbs)
CT PC34
3/4"
0.40
CT PC118 1-1/8"
0.40
No.
Description Wt (lbs)
CFA WB24 2x4
0.88
CFA WB26 2x6
1.00
FORM
ALIGNER
CLAMP
2X4
STIFF-BACK
ROTATE
WEDGE
TIGHTEN
WEDGE
WITH
HAMMER
SNAPTIE SYSTEM
