CONCRETE PLACING
Concrete Buckets
The "R" Series Concrete Bucket is 30% to 50% lighter than most standard steel buckets of the
same capacity. The Double Clamshell 16" diameter gate featuring the patented GarBro
venturi throat is non-jamming, grout tight, and self-closing. A variety of attachments are
available for all "R" series buckets, including rubber accordion hoppers, side chutes, air
operated gate systems, and extensions collars.
Sides Chutes
- Available with "R" series round buckets to concrete discharge to the side.
Rubber Acordion Hoppers
- These hoppers funnel concrete from a bucket into
narrow forms and prevent segregation due to free fall.
Elephant Trunk
Elephant trunks are available in either 8" or 12" diameters. Sold in 50 ft lengths.
Clamps
Steel clamps are furnished in one size that adjusts to fit both the 8" and 12" steel collars and
hoppers.
Collars
Steel collars are available in either 9" or 8" diameters or 13" to 12" diameters.
Hoppers
Hoppers are fabricated from high density polyethylene plastic, giving a rugged and sturdy
product while at the same time being very lightweight. The system can be easily assembled
and handled by one man. Adjustable hopper size 12" and 8".
12" Diameter
8" Diameter
No.
Cu Yards.
Cu. Ft.
Outside Dia In. Loading Height In. Wt (lbs)
GA 413R 1/2
13.50 38
41
257
GA 427R 1
27.50 56
46
400
GA 440R 1-1/2"
40.50 63
53
491
GA 454R 2
54.00 70
58
642
GA 483R 3
83.00 70
72
800
No.
Description
Length Below Bucket Discharge Opening Wt (lbs)
GA 409E All "R" and "G" Round 3lf
8"
21.00
No.
Size Wt (lbs)
GS 682 8"
43.00
GS 683 12"
64.00
No.
Size
Wt (lbs)
GS 690 One Size Fits All
0.06
No.
Size
Wt (lbs)
GS 688 9" to 8"
3.00
GS 689 13" to 12"
4.00
No.
Hopper Size Wt (lbs)
GS 484 36"x36"
25.00
CONCRETE PLACING EQUIPMENT
