MASCO Concrete Forming & Accessories (Updated 4/2016)

MASONS SUPPLY COMPANY

Oregon (800) 537-3407 ♦ Washington (800) 537-6216

M A S C O . N E T

Flex-Form

gives you all the strength and versatility

you need. Has 4" deep vertical stiffeners with 3/16"

steel skin plate to provide a 1000 psf system that

handles any radius 5' and over.

Pre-Rolled Steel Ribs Set the Radius

Rolled top and bottom ribs bolt to flexible panels

to shape and securely hold the form in the radius

you require. Panels conform precisely to the radius

of the ribs - this design assures that you'll get the

correct radius every time. And with a straight rib,

you can produce a straight wall if needed.

Perfectly Smooth Concrete

Because the steel skin plate flexes to form the

desired arc, there's no chording effect in the poured

concrete surface. Conventional panel systems

produce form joint marks that require grinding and

rubbing. Flex-Form

produces smooth concrete

surfaces that require little or no finishing labor.

Fast and Simple Erection

Panels are delivered to the job site pre-assembled

to your required radius. There are no expensive

templates to build; no need to torque bolts; just

begin erection labor.

If the job requires more than one radius, simply

order extra rolled ribs for use with the same forms.

Change over is quick and simple - done on the

site by job personnel. The new rolled ribs will

automatically set the new radius to the forms;

this will speed assembly and increase forming

productivity.

Stacking Panels

Panels can be stacked by bolting the top and

bottom ribs of adjacent forms with ¾" fit-up bolts

and nuts. Steel walkway brackets may also be

bolted to the vertical stiffeners to provide vertical

alignment. Pipe Form Aligners bolt directly to

vertical stiffeners as well.

Specifications

Skin plate thickness:

3/16"

Pressure rating:

1,000 psf

Panel/filler heights:

2', 3', 4', 5', & 6'

Width:

Panels - 4', 8', & 12'

Fillers - 4", 6" & 8"

Approximate Weight:

20 psf (assembled)

Thickness of panel:

4¼"

Minimum radius:

VERTICAL FORMING SYSTEMS

FLEX-FORM®
