VERTICAL FORMING SYSTEMS
SY 39760
32 lbs.
SY 39758
25 lbs.
SY 39756
18 lbs.
SY 39754
12 lbs.
18"
42"
42"
18"
120"
18"
30"
30"
18"
96"
18"
36"
18"
72"
12"
24"
12"
48"
The Steel Ply Gang Filler is designed to increase productivity by reducing the number
of ties required in conventional gangforming.
This 2" steel filler features preset tie hole locations in the face to accept 15 mm Taper
Ties (3/4" to 5/8"), She Bolts or Tie Rods with 15 mm Tie Nuts to secure the tie.
The Steel Ply Gang Filler is placed between each Steel Ply panel and connected
with a 3/4" x 4" flat coil bolt and nut (two connections are required per filler).
The Steel Ply Gang Filler is available in four lengths: 4', 6', 8', and 10'. Fillers can be
stacked for gangs taller than 10'.
All standard accessories are compatible with the gang filler, including the Double-
Duty Lift Bracket, the One-Piece Waler, Walkway Brackets and Turnbuckles.
STEEL PLY®
