Wedge Bolt
connections
enable unskilled laborers
to become consistently
productive. No special tools
are required, just a hammer.
Wedge Bolts connect panels
and capture ties at the
same time.
With a shorter length and slot than
a Wedge Bolt, the
Short Bolt
can
be used to attach the pilaster form
to a Steel-Ply form.
The
Base Tie Bolt
secures either a panel tie or a flat tie to
an end rail or a side rail (1) when resting on a footing, or (2)
where panels butt against existing vertical surface.
WEDGE BOLTS
SY 60058
The Long Bolt
similar to
the Wedge Bolt, is used to
connect the 1", 1½" and 2"
steel filler to adjust panels
and filler.
SHORT BOLTS
SY 60049
VERTICAL FORMING SYSTEMS
SY 60087
STEEL PLY PANEL OR FILLER
16d NAIL
BASE TIE BOLT
TIE
LONG BOLT
TIE
FILLER
PANEL TIE
LONG BOLTS
SY 60052
STEEL PLY®
