FOOTING FORMING
SLAB / HORIZONTAL
Fastfoot
®
Fastfoot is a fabric footing form. Stakes are driven into the ground, 2x4 screed boards attached at the correct
height, and Fastfoot is stapled to each 2x4 to form. Fast to install and less expensive than forming with lumber.
Lightweight—120' of fabric weighs only 12.4 lbs. Adapts to uneven ground. Less concrete, no leakage. In
summer, it prevents rapid desiccation of concrete. In winter, it prevents the contamination of concrete with
mud and water. Stay-in-place form, no stripping of fabric. No concrete damage to 2x4s, stakes. No leaching
of concrete contaminates into ground and water table. Can be used as a complete footing form, forming the
sides and base of the footing. It can also be used as an edge form, forming the sides only.
No.
Name
Width
Full Footing
Edging
Wt (lbs)
Qty/Ctn
Height
Width
Maximum
edge height
FF STD
Standard 62"
13"
24"
28"
13.0
4
FF WIDE
Wide
74"
13"
36"
34"
16.0
4
FF HF
Edge
37"
N/A
N/A
16"
8.0
16
Fabric Width Sizing Rule
Equals footing width +
twice height + 12"
Equals twice height + 6"
It is possible to form full footings deeper than those indicated in the table. For example, using the wide
fabric, a 24" wide footing can be formed, up to 19" deep. Use the Fabric Width Sizing Rule in these
situations. When using Fastfoot
®
for edging, the fabric is placed under the concrete to ensure no leakage
occurs along the bottom edge.
Profile of lumber-
formed footing
Fastfabric
®
2x4
Stake
Footing Width
Center-line
Saved
concrete
Extra
concrete
Nail
