MASONS SUPPLY COMPANY
Oregon (800) 537-3407 ♦ Washington (800) 537-6216
Clackamas | Eugene | West Eugene | Hillsboro | Medford | Portland | Salem | Wilsonville | Ridgefield | Seattle | Tacoma | Woodinville
M A S C O . N E T
SLAB/HORIZONTAL
CURB & EDGE FORMS
Flexible Forms
The Flexible Form is available in 10' lengths with heights
ranging from 4", 6" and 12", to satisfy almost any radius edge
forming condition. Each form has seven reinforced stakes
pockets on the back side that secure ¾" steel stakes and
support the form during concrete placement. A simple end
connection only requires a keybolt and wedge (or a nut and
bolt) to secure one form to another.
Flexible Forms complement Straight Forms when concrete
must be placed in radius or curved applications. Transition
Forms can be used to join the equipment and maximize
forming system productivity.
Special Forms
Other special forms are available to maximize productivity for
unique forming conditions. Filler Forms are used to overlap
Straight Forms and close edge openings up to 5'. Corner
Forms are used with Straight Forms for precise dimension
corner forming. Batter Plates are used with Straight Forms to
create a partial or full batter curb design.
PAVING FORM
SUPER FLAT FORM
FLEXIBLE FORM
(7-POCKET DESIGN)
Flexible Steel Design
will from radius as
small as 5 feet
Transition Form will
connect Flexible Form
to Straight Form
No.
Description
Wt (lbs)
DEE 410CSF
4" x 10' straight form, 3 pocket
39.0
DEE 610CSF
6" x 10' straight form, 3 pocket
47.0
DEE 1210CSF 12" x 10' straight form, 3 pocket
95.0
DEE 610CFF
6" x 10' J curb face form, 1" batter,
1" bottom radius,
40.0
DEE 512TS
5-1/2" top spreader
2.0
DEE 1218FDP 12" high x 18" wide division plate,
1" batter, 1" bottom radius
6.0
DEE 1218SDP 12" high x 18" wide skeleton divison
plate, 1" batter,
2.4
DEE 1224FDP 12" high x 24" wide division plate,
1" batter, 1" bottom radius
8.0
DEE 1224SDP 12" high x 24" wide skeleton divison
plate, 1" batter, 1" bottom radius
3.2
Other sizes available.
