SLAB/HORIZONTAL
Curb Forms
The Curb Forming System is a versatile product line that
adapts to many different concrete forming conditions.
It is ideally suited for applications that include sidewalks,
driveways, curb and gutters, pavements, footing and
industrial slabs.
This forming system features durable steel components,
with added reinforcement, for maximum service life.
These components are precision welded to provide a
system that lasts far longer than conventional lumber
edge forms.
The productivity advantages of this forming system
are obvious. The system adapts to different project
conditions, reducing applied forming costs. A crew
sets the system quickly and consistently, reducing
related labor costs. The steel design eliminates lumber
replacement costs, maximizing system reuse.
Straight Forms
The Straight Form is available in 10' lengths, with heights
ranging from 4", 6" and 12", to satisfy almost any straight
edge forming condition. Each form has reinforced stake
pockets on the back side that secure ¾" steel stakes
and support the form during concrete placement. The
rounded nose and connection of one form quickly
connects into the box of another form for accurate
alignment.
Straight Forms are most often used as edge forms for
concrete slabs. The bottom edge of the form rests on
the subgrade or the stake pocket holds the form at the
proper elevation. The top edge of the form provides
a place for lightweight screed equipment used during
concrete placement. Forms can even be stacked for
thick concrete slabs.
Straight Forms are also used to form a variety of curb
and gutter configurations. Curb dimensions establish
the shape of the Division Plates needed. The Plates are
then positioned over the Straight Forms to support the
Curb Face Form. The final concrete finish is applied after
the Curb Face Form and Division Plates are removed
(before final set).
USED WITH
STRAIGHT FORMS
FOR EXACT
DIMENSION SLABS
INSIDE AND OUTSIDE
CORNER FORMS
SKELETON PLATE
FULL PLATE
DIVISION PLATE
NAIL STAKE
FRONT FORM
TOP SPREADER
BACK FORM
CURB FACE
FORM
4" THROUGH 8"
9" THROUGH 16"
CURB & EDGE FORMS
