MASONRY
JOINT REINFORCING
Truss
Truss design is a prefabricated reinforcement for embedment
in the horizontal mortar joints of masonry. Manufactured
from wire conforms to ASTM A 83 for cold-drawn steel wire. It
consists of two 9 gauge deformed longitudinal wires welded
to a continuous 9 gauge diagonal cross wire at 16" O.C.
Out-to-out spacing is approximately 2" less than the nominal
thickness of the wall. Wire is hot dipped galvanized to meet
ASTM A-153, Class B. Other wire gauge available on request.
500 lf per bundle.
Ladur
Ladder design is a prefabricated reinforcement for
embedment in the horizontal mortar joints of masonry. It
is manufactured from wire conforming to ASTM A-82 for
cold drawn steel wire. It consists of two 9 gauge parallel
deformed longitudinal welded to perpendicular 9 gauge
cross wire. Out to out spacing is approximate two inches
less than the nominal thickness of the wall. Wire is hot dipped
galvanized to ASTM A-153, Class B2. Other wire gauge
available on request. 500 lf per bundle.
No.
Size
Wt/Bndl (lbs)
W 6LADUR
6"
65.0
W 8LADUR
8"
70.0
W 10LADUR
10"
75.0
W 12LADUR
12"
80.0
No.
Size
Wt/Bndl (lbs)
W 4KWEB
4"
90.0
W 6KWEB
6"
90.0
W 8KWEB
8"
95.0
W 10KWEB
10"
100.0
W 12KWEB
12"
105.0
16" O.C.
16" O.C.
Straight and Cut
For brick veneer walls. Standard 9 gauge deformed wire.
Packages in 10' lengths, 100 pieces or 1,000' per bundle.
Wire hot dipped galvanized to meet ASTM A-153, Class B.
No.
Description
Wt/Bndl (lbs)
W 9HD10 Hot Dipped
60.0
W 9SS
Hot Dipped Stainless Steel
60.0
