MASONRY
Expansion Joint
Horizontal Expansion Joint:
1/4"x2-3/4"x50' adhesive on one side;
compression up to 35%; manufactured of closed cell neoprene
conforming to ASTM D 1056, RE41.
Vertical Expansion Joint:
3/8"x3"x50' with no adhesive; compression up
to 35%; manufactured of closed cell neoprene conforming to ASTM
D-1056, RE 41.
No.
Wt (lbs)
DA 2010
2.5
No.
Wt (lbs)
DA 2015
3.0
DW-10HS
®
Anchors
Primarily for use when there is no insulation and little potential
for wallboard deterioration. DW-10HS is 6" long with 3-5/8"
vertical adjustability. Stocked in 14 gauge Hot Dip Galvanized.
12 gauge and Type 304 Stainless Steel is available on a special
order basis. All anchors furnished with 9/32" diameter holes.
No.
Size Qty/Ctn Wt (lbs)
HB DW10HS
6"
250
43.0
Swaged to accept
continuous wire.
Upward pitch
rear leg
Upward pitch
front leg
BYNA-Lok
™
Ties
Swage & mild pitch on legs of the Byna-Lok™ Wire Tie provide
an integral track for continuous joint reinforcing wire. Suitable
for standard 3/8" mortar joint. More surface engagement
of the continuous wire and the integral track than any
other system on the market. Reduces potential for incorrect
placement or disengagement of the continuous wire due to
workmanship error. Hassle-free installation of the continuous
wire into the Byna-Lok™ Wire Tie. Economical; add continuous
wire to masonry walls at little additional cost. Suitable for use
with a variety of H&B anchors. Available 3/16" dia. x 3", 4", and
5" long, Hot Dip Galvanized finish. Type 304 Stainless Steel on a
special order basis.
No.
Size Qty/Ctn Wt (lbs)
HB 3BL
3"
250
21.0
HB 4BL
4"
250
25.0
HB 5BL
5"
250
28.0
BRICK TIES
