MASONRY
BRICK TIES
DA431
DA131
CORRUGATED WALL TIES
Seismic Strap Anchor
DA 431 is a special 14 gauge seismic corrugated veneer anchor with
two shear lugs, which is engineered for use with pencil rod to resist out
of plane movement and afford greater ductility in seismic zones 3 and
4. Designed to be screwed to wood or steel stud backup.
Seismic Dovetail Anchor
DA131 is a 16 gauge adjustable seismic corrugated veneer an-
chor with two shear lugs, which is engineered for use with pencil
rod to resist out of plane movement and afford greater ductility
in seismic zones 3 and 4. Engineered to fit standard dovetail slot
with 5/8" throat opening.
Corrugated Wall Ties
Residential non-seismic brick ties available in mil galvanized
steel 7/8" wide and 7" long: thickness 22 and 16 gauge.
Stainless Screws
Stainless Steel is available with and without washers.
This self-drilling screw has a hardened point for easy
installation. Is frequently specified on stainless steel anchor
jobs. The maximum in corrosion resistant.
Coated Screws
The maximum in corrosion resistant coating. Attractive silver-
grey finish covers entire fastener surface. Compatible with
painted or metal surfaces. Out performs existing mechanical
and electro-platings. Does not promote corrosion that can be
caused by electrochemical reaction between dissimilar metals.
No.
Size
Qty/Ctn Wt/Ctn (lbs)
DA 431-3 3-1/2"
250
37.5
DA 431-4 4-1/2"
250
42.5
No.
Size
Qty/Ctn Wt/Ctn (lbs)
DA 167WT 16 ga.x 7"
500
55.0
DA 227WT 22 ga. x 7"
1,000 55.0
DA 227WT-T 22 ga. x 7"
1,000 55.0
No.
Description
Qty/Ctn Wt/Ctn (lbs)
TEC 1012SS
#10 x 1-1/2"
1,000 17.0
TEC 10112SSW #10 x 1-1/2" w/washer 1,000 20.0
No.
Description
Qty/Ctn Wt/Ctn
(lbs)
Metal Studs:
TEC 10112HC #10 x 1-1/2"
3,000 34.0
TEC 10112HCW #10 x 1-1/2" (w/washer) 2,500 30.0
Wood Studs:
TEC 102WW #10 x 2" (w/washer)
2,000 30.0
No.
Size
Qty/Ctn Wt/Ctn (lbs)
DA 131-3 3-1/2"
250
20.0
DA 131-4 4-1/2"
250
25.0
DA 131-5 5-1/2"
250
30.0
Dovetail Slot available see page 83.
