FASTENERS
FASTENERS
Spike
The Spike is a patented all-steel, one piece, vibration
resistant anchor for use in concrete, block, brick or
stone. Using a special manufacturing process, the
anchor is formed with "S" shaped configuration at the
working end of the anchor to create an expansion
mechanism. The spring action of the expansion
mechanism is developed through the use of a heat
treatment, cold working process, or die-casting
depending upon the Spike style. The carbon steel
Spike is manufactured from steel which is heat
treated to provide a high tensile and shear strength
equivalent to Grade 8.2 material. The steel is plated
with commercial bright zinc and a supplementary
clear chromate treatment according to ASTM B633.
Carbon Steel - Zinc Plated
Forming Spike
The Forming Spike is designed to securely fasten forms and
related brackets to concrete and other masonry materials.
It is made of through-hardened, steel which enables it to
be reused several times with no loss of holding power. The
double head of the Forming Spike makes removal fast and
easy. Its small diameter provides quick installation and
requires less time to patch the hole when removed.
Carbon Steel - Zinc Plated
Tie-Wire Spike
The Tie-Wire Spike is the ideal choice for installing
acoustical ceiling under concrete decks. Drilled holes
are smaller than conventional anchors used with eye-
bolts, so installation is faster and less expensive.
Carbon Steel - Zinc Plated
Snap Spike
A one piece, nylon anchor for use in concrete, brick or
block. It is available in 1/4" x 2" for use in temporary, light
duty forming applications such as tilt wall reveal strip where
1x or 2x lumber is used. The anchor is molded with an "S"
shaped configuration at the working end of the anchor to
create an expansion mechanism and a taper formed on
the upper shank of the anchor to hold the 1x or 2x material
securely in place. Once the application is completed,
simply pry the lumber over the head of the anchor then
shave the anchor with your scraper to snap the protruding
tapered shank section off leaving the remaining portion of
the anchor flush with the base material.
No.
Size
Wt (lbs)
Qty/Ctn
RL 5502
3/16" x 1"
.013
100
RL 5503
3/16" x 1-1/4" .015
100
RL 5504
3/16" x 1-1/2" .018
100
RL 5506
3/16" x 2"
.020
100
RL 5508
3/16" x 2-1/2" .030
100
RL 5522
1/4" x 1"
.015
100
RL 5523
1/4" x 1-1/4"
.023
100
RL 5524
1/4" x 1-1/2"
.025
100
RL 5526
1/4" x 2"
.030
100
RL 5528
1/4" x 2-1/2"
.040
100
RL 5530
1/4" x 3"
.045
100
RL 5531
1/4" x 3-1/2"
.050
100
RL 5551
3/8" x 3-1/2"
.110
25
RL 5552
3/8" x 4"
.120
25
RL 5554
3/8" x 5"
.180
25
RL 5571
1/2" x 3-1/2"
.220
50
Also available in stainless steel.
1000
2000
6000
Driver Tool
No.
Spike Size
Description
RL 3790 3/16" - 1/4"
1,000 - SDS end
RL 3791 3/16" - 1/4"
2,000 - Attaches to SDS bit
RL 3894 3/8" - 1/2"
6,000 - Spline end
No.
Size
Drill Diameter
Qty/Ctn Wt (lbs)
RL 6685 1/4" x 2"
1/4"
100
.75
No.
Size
Wt (lbs)
Qty/Ctn
RL 3759 1/4"
.025
100
No.
Size
Wt (lbs)
Qty/Ctn
RL 3795 3/16" x 1-1/2"
.03
100
RL 3797 3/16" x 2-3/4"
.04
100
RL 3794 1/4" x 2-3/4"
.05
100
RH FD6234 3/16" x 2-3/4"
.03
100
RH FD8234 1/4" x 2-3/4"
.06
100
ICC and SWL information available on request.
