FASTENERS
Steel Drop-In
A fully assembled, highly versatile, internally expanded steel anchor
for medium and heavy loads in solid concrete. Easily installed and
once set the bolt, stud or threaded rod can be easily removed or
replaced without affecting the Drop-In’s holding power. Stocked in
zinc plated.
Carbon Steel - Zinc Plated
Coil Anchor
A removable 3/4" coil anchor with a hex head.
Drill hole size the same as the anchor. It is also
removable and reusable. Insert the assembled
COIL ANCHOR through the foot plate of the pipe
brace into a properly drilled hole. Tap the COIL
ANCHOR bolt all the way into the hole so that the
washer and bolt head rests on the foot plate of
the brace.
Carbon Steel - Zinc Plated
n/c Thread
coil thread
No.
Size Wt (lbs) Qty/Ctn
N/C Thread
RL 6304
1/4"
.02
100
RL 6306
3/8"
.06
50
RL 6308
1/2"
.12
50
RL 6320
5/8"
.32
25
RL 6312
3/4"
.48
10
Also available in stainless steel.
Coil Thread
RL 6330
1/2"
.12
50
RL 6332
3/4"
.48
10
Setting Tools
RL 6305
1/4"
RL 6307
3/8"
RL 6309
1/2"
RL 6311
5/8"
RL 6313
3/4"
No.
Description Wt (lbs)
Qty/Ctn
DS 49206
3/4" x 4-1/2" .61
20
DS 123045
3/4" x 6"
.78
10
DS 49203
Tang only .04
Drive Rivet
Used for attaching steel ply side rails to
1/2" plywood.
No.
Size
Qty/Ctn Wt/Ctn (lbs)
SY 60119 1/2" Plywood 1,000 5 lbs.
ANCHOR
WASHER
4 TURN TANG
.740"
MAXIMUM
TANG O.D.
FASTENERS
ICC and SWL information available on request.
