FASTENERS
Power Bolt
The Power Bolt is a single unit, vibration-resistant, removable anchor bolt assembly with a finished hex or flat head
design. Since the anchor size is hole size, the Power Bolt eliminates layout or hole-spotting. As the anchor is driven
into the hole, the slotted, over-sized annular ring on the bottom of the cone is compressed until it mates perfectly with
the hole. This action prevents the anchor from spinning while it is being tightened. Carbon steel power bolt anchors
are manufactured using a Grade 5 bolt. They have a commercial bright zinc finish and a supplementary chromate
treatment in accordance with ASTM specification B633.
Carbon Steel - Zinc Plated
Wedge Anchor
A heavy-duty, all steel, expansion wedge anchor
designed to work under dead and variable loads
in solid concrete. A complete fastening system;
anchor, nut and washer are inserted as a single unit
and all at the same time.
Carbon Steel - Zinc Plated
ICC and SWL information available on request.
No.
Size
Wt (lbs) Qty/Ctn
RH WS1416 1/4" x 1-3/4"
.03
100
RH WS1422 1/4" x 2-1/4"
.04
100
RH WS1432 1/4" x 3-1/4"
.05
100
RH WS3822 3/8" x 2-1/4"
.08
50
RH WS3826 3/8" x 2-3/4"
.10
50
RH WS3830 3/8" x 3"
.11
50
RH WS3836 3/8" x 3-3/4"
.12
50
RH WS3850 3/8" x 5"
.15
50
RH WS1226 1/2" x 2-3/4"
.18
25
RH WS1236 1/2" x 3-3/4"
.23
25
RH WS1244 1/2" x 4-1/2"
.28
25
RH WS1254 1/2" x 5-1/2"
.32
25
RH WS1270 1/2" x 7"
.44
25
RH WS5834 5/8" x 3-1/2"
.36
10
RH WS5842 5/8" x 4-1/4"
.41
10
RH WS5850 5/8" x 5"
.47
10
RH WS5860 5/8" x 6"
.54
10
RH WS5884 5/8" x 8-1/2"
.80
10
Also available in stainless steel.
No.
Size
Wt (lbs) Qty/Ctn
RH WS5870
5/8" x 7"
.62
10
RH WS3442
3/4" x 4-1/4"
.68
10
RH WS3446
3/4" x 4-3/4"
.76
10
RH WS3454
3/4" x 5-1/2"
.85
10
RH WS3462
3/4" x 6-1/4"
.95
10
RH WS3470
3/4" x 7"
.97
10
RH WS3484
3/4" x 8-1/2"
1.20
10
RH WS34100 3/4" x 10"
1.40
10
RH WS34120 3/4" x 12"
1.66
10
RH WS7860
7/8" x 6"
1.20
5
RH WS7880
7/8" x 8"
1.60
5
RH WS78100 7/8" x 10"
2.00
5
RH WS10060 1" x 6"
1.70
5
RH WS10090 1" x 9"
2.40
5
RH WS100120 1" x 12"
3.00
5
RH WS12590 1-1/4" x 9"
.60
5
Also available in stainless steel.
No.
Size
Wt (lbs) Qty/Ctn
RL 6913
3/8" x 3"
0.11 50
RL 6916
3/8" x 4"
0.14 50
RL 6930
1/2" x 2-3/4" 0.16 50
RL 6932
1/2" x 3-3/4" 0.21 25
RL 6934
1/2" x 4-3/4" 0.26 25
RL 6956
3/4" x 7-1/4" 1.05 10
RL 6957
3/4" x 8-3/4" 1.10 10
Flare Head
RL 6983
3/8" x 6"
0.20 50
Also available in stainless steel.
