POUR IN PLACE
No.
Description
Wt
(lbs)
Channel Base Section
ZN 884-CHANNEL 40" Polypropylene D.Grey Channel -
Outlet Adapters
ZN 884-E1
Closed End Cap
-
ZN 884-E2
2" No-Hub End Outlet
-
ZN 884-U3
3" No-Hub Bottom Outlet
-
Decorative Grate Options
ZN P4-CG 20" Cast Iron Slotted Grate (B)
-
ZN P4-4HPP
Heel-Proof Polyethylene Grate,
Dark Grey (A)
-
No.
Description
Wt
(lbs)
Channel Base Section
ZN 880-CHANNEL 4' High Density Polyethylene
Drain Channel with Grey Grate -
Outlet Adapters
ZN 880-E1
Closed End Cap
-
ZN 880-E150
1.5" No-Hub End Outlet
-
ZN 880-U150
1.5" No-Hub Bottom Outlet
-
Miscellaneous Options
ZN 880-C45
45 Degree Channel
-
ZN 880-C90
90 Degree Channel
-
Deck Drain
Deck Drain is a removable top drain that features
a double wall base and snap in top (PVC). When
installing this drain the tops are staggered past
the joints making the joints very rigid. Because the
tops are removable, this drain is easy to clean and
the tops can be replaced if ever damaged. Deck
Drain is used in many residential and commercial
swimming pools, patios and other pedestrian traffic
areas. Color is grey.
No.
Description Qty/Ctn Wt (lbs)
STG SDDG 10' Deck Drain
8
STG SDDTCG 10' Gray Top Cap 8
STG SDD90G 90 Degree
10
STG SDD-TW Tee
4
STG DEA
End Adapter
4
STG DEP
End Plug
10
STG DCUP
Coupler
12
This drain is not designed to be used as a full
expansion. It requires that a 3/8" rebar be
placed every 36", midway in the drain to prevent
damage due to concrete deck movement.
TRENCH DRAIN
4 inch Width (ZN 884)
• Made of 0% water absorbent Polypropylene
• Weigh less than 2 lbs per linear foot
• 4 inches (4-3/4”) wide
• 40 inch sectional length
• 1.634 inch bottom radius
• 3 inch depth
• .009” neutral bottom slope
• 20 inch, tie-down/leveling intervals
• Furnished with Heelproof Polypropylene grates
2 inch Width (ZN 880)
• Made of High Density, UV-10 stable Polyethylene
• 2 inches (2-1/2”) wide
• 48 inch sectional length
• 3 inch depth
• Neutral bottom (no slope)
• Tongue and Groove snap fit connections
• 24 inch, tie-down/leveling intervals
• Furnished with High-Density Polyethylene grates
