POUR IN PLACE
No.
Size
Description
Wt/Lf (lbs)
JP 436 4" x 3/16" Ribbed Center Bulb 0.40
JP 636 6" x 3/16" Ribbed Center Bulb 0.70
JP 936 9" x 3/16" Ribbed Center Bulb 1.07
Factory Made Splices Available
● Eliminates intricate field splicing.
● Permits faster waterstop installations.
● Insures correct splicing in critical areas.
● Eliminates guesswork.
Heating Iron
For PVC Waterstop, cut ends square and hold both sides against
iron to 350°- 380° F. Do not allow the iron to reach 400° F, PVC will
degrade and turn dark color. When about 1/8" to 1/4" of material
becomes soft and gummy, remove the iron and press ends
firmly together. Hold tightly and allow material to cool before
applying stress. All center bulb waterstop must be aligned.For TPE
Waterstop preheat iron to 380° to 410° F. 115 volt, 6 amps, 6' cord.
Hog Ring
7/8" opening hog rings should be placed at the outer most rib of
waterstop 12" on center. Tie off to reinforced steel.
Hog Ring Plier
Chemical Resistent
TPE-Rubber Waterstops greatly expand the scope of
conventional Waterstops because they do not degenerate
under a host of aggressive chemicals, solvents and hot
petroleum oils that would destroy PVC. TPE Rubber Waterstops
are capable of withstanding joint movement. TPE Rubber
Waterstops also have an added advantage of being joined with
our regular Waterstop Splicing Irons. The intended use for TPE
Rubber Waterstops is for primary and secondary containment
facilities where compatibility, resistance and performance values
determine the choice based on the specific application test
data. TPE Rubber Waterstops are available in 4", 6" and 9" ribbed
centerbulb design; which provides for movement within a joint
and may be used for above or below grade applications.
No.
Wt (lbs)
CT HRP 0.50
No.
Size
CT HR #3, 25 lbs/carton (88 pieces/lbs approx)
No.
Size
Wt (lbs)
GS 214
2" x 14"
4.00
GS 214C 2" x 14" Teflon Cover
0.17
GS 414
4" x 14"
8.00
GS 414C 4" x 14" Teflon Cover
0.34
GS 414
GS 214
Vertical Ell
Flat Ell
Vertical Tee
Flat Tee
Vertical Cross
Flat Cross
WATERSTOP
