POUR IN PLACE
MC-2010MN
Pre-formed rubber strip with stainless steel net. Used to replace
conventional PVC waterstops in construction joints and control joints.
Will withstand high hydrostatic head and intermittent exposure to rain
or water. Expands up to 2 times by volume. Embedded wire mesh
promotes vertical expansion vs longitudinal. Attach with screws, nails,
glue, P-201 (may need nails or screws with P-201). Can be used on
rough concrete with P-201. NSF certified for potable water.
Minimum Use Conditions:
Wall/slab thickness greater than 9" (10" recommended).
Minimum 4" concrete coverage - 6.5 ft. wall height (check with
Masons for variations).
Between double row of rebar.
Below grade or water present either side of wall/slab joint.
MC-2005M
Pre-formed rubber strip with stainless steel net. Use between joints or
structural elements where expected joint opening does not exceed
0.05". Will withstand intermittent exposure to rain or water. Expands
up to 2 times by volume. Embedded wire mesh promotes vertical
expansion vs longitudinal. Attach with glue or P-201 (may need
screws with P-201). Can be used on rough concrete with P-201.
Minimum Use Conditions:
Wall/slab thickness greater than 9" and less than 24".
Minimum 4" concrete coverage - 6.5 ft. wall height (check with
Masons for variations).
Between double row of rebar.
Below grade or water present either side of wall/slab joint.
Hydrostatic head less than 50 ft.
Hydrophilic
Hydrophilic waterstop is a chemically modified natural rubber. This
patented process chemically binds hydrophilic agent to the rubber.
This permits the seal to undergo controlled expansion when in the
presence of moisture. This expansion capability provides a "double
locking" waterstop. One from rubber's natural resilience and one
from the expansion. Any void within the limits of the products volume
expansion coefficient, will be filled by the expansion of the seal
when it is hydrated. Excellent durability and resistance to chemicals.
It can perform in a wide range of solutions such as salt water and
cement water. The material does not contain any toxic substance or
heavy metals and is environmentally safe.
No.
Size
Qty/Ctn Wt/Ctn (lbs)
ADE MC2010MN 20 mm x 10 mm
(.78" x .39")
82 lf
17.50
No.
Size
Qty/Ctn Wt/Ctn (lbs)
ADE MC2005M 20 mm x 5 mm
(.79" x .20")
165lf
35.00
No.
Size
Wt (lbs)
ADE Q2141
1Qt
2.50
Contact Adhesive
2141 Adhesive:
is easy-brushing, general
purpose rubber adhesive with excellent
water resistance. Good for concrete,
steel, neoprene, butyl and natural rubber.
Surface must be clean, dry and dust free.
Apply adhesive to both surfaces and
allow to initially dry, typically 5-10 minutes.
Press surfaces together. Bond life is up to
15 minutes. Coverage is 82 lf/qt.
80 Spray Adhesive
Description
: Neoprene-based aerosol
contact adhesive. Plasticizer resistance.
High temp. resistance to 200° F. Fast
drying; Fast bonding. Durable - high
strength adhesive.
Application
: Bond all types of rubber
except EPDM. Bond most supported vinyl,
leather. Adhere stainless steel panels,
stiffeners, and metal kick plates. Adhere
many plastics, laminate and wood
products. Recommended for bonding
ADEKA preformed waterstops.
Coverage
: 24oz. canyields =approx. 75 ft
2
No.
Size
TM 80
24 oz. can, 12/case, 13 lbs.
WATERSTOP
