| CAST I PLACE DETECTABLE WARNING PANEL 2' x 2'
PART# MA CT22
All dimensions in inches
24"
1.425"
1.425"
9SPC'S@2.35"=21.15"
23.5"
1.175"
1.175"
9SPC'S@2.35"=21.15"
24.375"
FINESANDBLAST
TEXTURE
0.9"
0.20"
1.0"
0.60"
0.25"
RADIUS
0.9"
0.20"
1.0"
0.60"
0.1875"
0.1875"
0.25"
RADIUS
CASTinTACT.com
For more information please visit:
24"
1.425"
1.425"
9SPC'S@2.35"=21.15"
30.55"
1.175"
1.175"
12SPC'S@2.35"=28.20"
24.375"
FINESANDBLAST
TEXTURE
0.9"
0.20"
1.0"
0.60"
0.25"
RADIUS
0.1875"
0.1875"
CASTinTACT.com
For more information please visit:
MASCO CASTinTACT
®
3
| CAST IN PLACE DETECTABLE WARNING PANEL 2.5' x 2'
PART# MA CT2.52
All dimensions in inches
36"
1.550"
1.550"
14SPC'S@2.35"=32.90"
23.5"
1.175"
1.175"
9SPC'S@2.35"=21.15"
36.375"
FINESANDBLAST
TEXTURE
0.9"
0.20"
1.0"
0.60"
0.25"
0.1875"
0.1875"
MASCO CASTinTACT
®
3
| CAST IN PLACE DETECTABLE WARNING PANEL 3' x 2'
PART# MA CT32
MASCO CASTinTACT
CAST-IN-PLACE DETECTABLE
WARNING PANEL 24" x 24"
PART # MA CT22(CLR)
MASCO CASTinTACT
CAST-IN-PLACE DETECTABLE
WARNING PANEL 30" x 24"
PART # MA CT2.52(CLR)
MASCO CASTinTACT
CAST-IN-PLACE DETECTABLE
WARNING PANEL 36" x 24"
PART # MA CT32(CLR)
Panel Drawings
Concrete Tactile Warning Panels
2 "
24
24.3 5"
24.3 5"
9 SPC'S 2.35" = 21.15"
.425"
9 SPC'S @ 2.35" = 21.15"
1.425"
1.425"
1.425"
FINE
SANDBLAST
TEXTURE
FINE
SANDBLAST
TEXTURE
.175"
1.175"
9 SPC'S @ 2.35" = 21.15"
23 5"
12 SPC'S @ 2.35" = 28.20"
30. 5"
FINE SANDBL ST
TEXTURE
3 "
14 SPC' @ 2.35" = 32.90"
1.550"
1.550"
1.175"
1.175"
.175"
23 5"
1.175
36.375"
9 SPC'S @ 2.3 " = 21.15"
CASTinTACT
®
