TIEING/HANDSET
SWL information available on request.
Steel Drop-In
Is a fully assembled, highly versatile, internally
expanded steel anchor for medium and heavy loads
in solid concrete. Easily installed and once set the
bolt, stud or threaded rod can be easily removed
or replaced without affecting the Drop-In’s holding
power. Stocked in zinc plated, stainless available.
SWL information available on request.
Nut - N/C
Nuts are used with all sizes of N/C bolts and rod. The
nuts are fabricated from carbon steel.
No.
Size Wt (lbs)
Qty/Ctn
RL 6304
1/4"
0.02
100
RL 6306
3/8"
0.06
50
RL 6308
1/2"
0.12
50
RL 6320
5/8"
0.32
25
RL 6312
3/4"
0.48
10
Setting Tools
RL 6305
1/4"
RL 6307
3/8"
RL 6309
1/2"
RL 6311
5/8"
RL 6313
3/4"
No.
Size Wt (lbs)
CT 12NUT
1/2"
0.04
CT 58NUT
5/8"
0.08
CT 34NUT
3/4"
0.12
CT 1NUT
1"
0.32
MIN DEPTH EQUALS ANCHOR LENGTH
DRILL HOLE
HOLE MUST BE CLEANED OF DUST AND OTHER MATERIAL
DROP-IN ANCHOR
1. DRILL HOLE FOR EXPANSION ANCHOR
2. INSERT EXPANSION ANCHOR INTO HOLE AND TAP FLUSH
3. USING A SETTING TOOL, SET ANCHOR BY DRIVING UNTIL SHOULDER
OF THE SETTING TOOL IS SEATED AGAINST THE ANCHOR
ALL THREAD
