TIEING/HANDSET
Cast Wing Nut
The cast wing nut is available in all diameters. It is
fabricated from ductile steel. Utilized when frequent
removal and application of a nut is required.
SWL provides a factor of safety of approximately 2 to 1.
Washer
Washers are used with all sizes of bolts
and rod. The washers are fabricated
from carbon steel.
Coil Coupler
Provides an efficient an safe alternative to conventional
forming of protruding coil rod. Allows for fast stripping and
worker safety by completing the splice at a later time.
No.
Size
SWL Tension (lbs)
Wt (lbs)
DS 34WN 3/4"
18,000
0.90
DS 1WN 1"
38,000
1.07
DS 114WN 1-1/4"
52,000
1.22
DS 112WN 1-1/2"
80,000
2.86
No.
Size
Wt (lbs)
CT 12WASH 1/2"
0.04
CT 58WASH 5/8"
0.08
CT 34WASH 3/4"
0.11
CT 1WASH 1"
0.17
CT 114WASH 1-1/4"
0.21
No.
Size
SWL Tension (lbs)
Wt (lbs)
DS 12CC 1/2"
9,000
0.20
DS 34CC 3/4"
18,000
0.40
DS 1CC 1"
38,000
1.50
COIL THREAD
