FORM BRACE ALIGNER
2 x 4
2 x 6
The Light SuperTie System offers an ultimate tensile strength of 6,000 lbs (3,000 pounds safe working load at 2:1 safety
factor), and is most commonly used with job-built (plywood and 2 x 4) forms. The fiberglass rod diameter is only
.308 inches, making the system compatible with most commercial forming systems. The fiberglass tie will never rust, so
no breakback or tie removal is required. Many dollars in labor are saved by using SuperTie, while aesthetically superior
architectural finishes result. It also reduces costs in battered wall and "odd sized" tie situations, since the rod is cut to the
length required at the job site.
SuperTie Fiberglass System
Accessories
Rod
No.
Rod
Pcs/Bundle Wt (lbs)
RJ B100
.308" x 20'
50
60.0
Plate Washer
No.
Size
Rod Diameter Wt (lbs)
CFA PW331412 3" x 3" x 1/4"
1/2"
0.65
Turnbuckle Form Aligners
Turnbuckle Form Aligners are designed to
accurately position and plumb vertical forms.
The turnbuckle section of the aligner features
a 1" diameter self-cleaning coil thread for fast
adjustments. The standard aligner has bent
nailing plate equipped with nail holes and a
15/16" hole to accept 3/4" or 7/8" steel stakes.
The safe working load of the aligners is limited
by the lumber, nailing and/or staking methods.
Rod, Gripper and Bearing Plate - the basic components of
the Light and Medium Systems
No.
Wt (lbs)
Gripper
RJ GND6000
1.0
Standard Form Aligner
NAILER PLATE FOR
JOB BUILT FORMS
1" DIAMETER
COIL THREAD
TURNBUCKLE
NAIL HOLES
No.
Wt (lbs)
RC TB
8.0
