Lift Bracket
The Alisply
™
Lift Bracket is attached by lifting the
release handle as shown, sliding the Lift Bracket
onto the form and, with a downward motion of
the lever, securing the Lifting Bracket to the panel.
The Lift Bracket can be attached anywhere along
the endrails or siderails.
The safe load rating of the Alisply Lift Bracket is
2200 lbs at a 5:1 safety factor. The number of Lift
Brackets required shall be determined by the
contractor based upon the weight of the gang
to be lifted. The rigging must be designed by the
contractor to assure that any one Gang Lifting
Bracket is not overloaded. Load equalizer beams
are recommended for all but simple two point lifts.
A minimum of two lift lines must be used to control
movement of the gang form. Do not allow
personnel on or directly under any gang form
while it is being moved or suspended in air.
Caution:
Do not initiate breaking a gang form
loose from a wall by lifting or tugging backward
through the Alisply Lift Bracket.
VERTICAL FORMING SYSTEMS
Lift Bracket and Attachment
SY 54553
Tyipical Lift with Two Lines
MIN 60
O
ALISPLY™
