Transition Filler

The all-steel 8" Transition Filler provides a convenient

connection between Alisply™ to Steel-Ply

, Versiform

and the Max-A-Form

concrete forming systems. The most

common use of the Transition Filler is for forming details,

such as corners and pilasters.

One side rail of the Transition Filler is clamped to an Alisply

panel or filler and the other side rail is either wedged

bolted or bolted to the adjacent panel. A vertical row

of flat ties is required at the connection between the

Transition Filler and Steel-Ply.

Walkway Bracket

The Alisply Walkway Bracket is manufactured with a

guardrail post. The guardrail post has two “L” brackets with

nail holes welded to it for attachment of lumber guardrails.

At the bottom of the post is a sliding “L” bracket with

nail holes to attach a toeboard. The Walkway Bracket

is attached to the forms at one of the accessory holes

on vertical crossmembers with the attached pin. If the

crossmembers are running in the horizontal direction,

the Walkway Connector is bolted to the crossmember

and the Walkway Bracket is attached to the Walkway

Connector. The capacity of the Walkway Bracket is 400

lbs. at a 4:1 safety factor (5 ft. maximum spacing).

Bulkhead Rod

The Bulkhead Rod is used with double 2x lumber or steel

walers, plywood or solid lumber and plate & nut to create

a job-built bulkhead. The capacity of the Bulkhead Rod is

4400 lbs. at a 2.5:1 safety factor.

No.

Description

Wt (lbs)

SY 722308 8" x 8'-0" Trans. Filler

128

SY 722306 8" x 6'-0" Trans. Filler

SY 722304 8" x 4'-0" Trans. Filler

WALKWAY CONNECTOR

SY 722300

Walkway Bracket Application

WALKWAY BRACKET ATTACHED TO

VERTICAL CROSSMEMBERS

SY 54554

SY 54552

VERTICAL FORMING SYSTEMS

BULKHEAD ROD AND TYPICAL APPLICATION
