Adjustable Joist Hanger
The Adjustable Joist Hangers are manufactured in two sizes.
The C-65 hanger is sized to accept 2x joist material and the
C-65-S hanger is designed to accept 4x joist material. Both
models are fully adjustable and are adaptable to concrete
beams, steel girders and box culverts. The Adjustable Joist
Hangers are 100% reusable and are load rated at 3,000
pounds safe working load.
SWL provides a factor of safety of approximately 2 to 1.
No.
Size
Wt (lbs)
DS C65
2x Joist
6.00
DS C65S
4x Joist
8.00
DS C65SC 4x Cover Shield
0.30
HORIZ. FORMING & SHORING
Cover Shield
C-65 for 2x
Material
5" max. adj.
C-65-S for
4x Material
6
½
" max. adj.
ADJUSTABLE JOIST HANGER TYPICAL APPLICATIONS
HANGERS
