Optional Waterseal Washer
Optional Waterseal Washers provide a tight fitting 3/4" diameter
neoprene washer located near the center of the tie. This helps
eliminate water seepage along the tie by breaking the surface
continuity of the wire.
Available on request.
Standard Plastic Cone (PC)
Standard Snapties are manufactured from medium high carbon
wire and 1"x1" plastic spreader cone providing a nominal 1"
breakback. 1-3/16" end uses 3/4" plywood and wedge. 1-5/8"
end uses 1-1/8" plywood and wedge. 4-3/4" end uses 3/4"
plywood, 2x4 walers and wedge. 5-1/8" end uses 1-1/8" plywood,
2x4 walers and wedge. 8-1/4" end uses 3/4" plywood, 2x4 walers,
2x4 strongback for formwork alignment and wedge. Special ends
available on request. Standard Snapties provide a safe working
load of 2,250 lbs. Adequate end clamps are required to develop
safe working loads.100 pieces per carton.
SWL provides a factor of safety of approximately 2 to 1.
Wrench Head
The six sided snaptie is produced with a high quality, uniform
shaped hot forged head. This six sided head permits break
back of ties while the formwork is still in place. The tie uses a
1"x1" plastic cone to provide a nominal 1" break back. Use
a 6 point 1/2" socket wrench to break back. After ties are
broke-off, then the forms can easily be removed which greatly
increases the speed of stripping resulting in significant labor
savings. Masons cannot guarantee that ends longer than
4-3/4" will consistently breakback. Standard Snapties provide
a safe working load of 2,250 lbs. Adequate end clamps are
required to develop safe working loads.100 pieces per carton.
Plastic cones
Plastic Cones are recommended when specifications require
a nominal 1" or 1-1/2" breakback. Plastic cone sizes other than
listed are available on special order.
WALL THICKNESS
BREAKBACK
LUMBER
AND
WEDGE
LUMBER
AND
WEDGE
No.
Size
Wt/Ctn (lbs)
CT 61316PC
6" x 1-3/16"
22.5
CT 6158PC
6" x 1-5/8"
22.5
CT 6SE
6" x 4-3/4"
23.5
CT 65PC
6" x 5-1/8"
25.0
CT 6LE
6" x 8-1/4"
32.0
CT 81316PC
8" x 1-3/16"
25.0
CT 8158PC
8" x 1-5/8"
25.0
CT 8SE
8" x 4-3/4"
26.0
CT 85PC
8" x 5-1/8"
27.0
CT 8LE
8" x 8-1/4"
34.0
CT 101316PC 10" x 1-3/16"
30.0
CT 10158PC
10" x 1-5/8"
30.0
CT 10SE
10" x 4-3/4"
28.0
CT 105PC
10" x 5-1/8"
29.0
CT 10LE
10" x 8-1/4"
37.0
CT 121316PC 12" x 1-3/16"
30.0
CT 12158PC
12" x 1-5/8"
30.0
CT 12SE
12" x 4-3/4"
31.0
CT 125PC
12" x 5-1/8"
32.0
CT 12LE
12" x 8-1/4"
39.0
MST 14SE
14" x 4-3/4"
33.0
MST 14LE
14" x 8-1/4"
41.0
MST 16SE
16" x 4-3/4"
35.0
MST 16LE
16" x 8-1/4"
43.0
MST 18SE
16" x 4-3/4"
38.0
MST 18LE
18" x 8-1/4"
46.0
MST 20SE
20" x 4-3/4"
40.0
MST 20LE
20" x 8-1/4"
48.0
MST 22SE
22" x 4-3/4"
42.0
MST 22LE
22" x 8-1/4"
50.0
MST 24SE
24" x 4-3/4"
44.0
MST 24LE
24" x 8-1/4"
53.0
MST 30SE
30" x 4-3/4"
51.0
MST 30LE
30" x 8-1/4"
59.0
MST 36SE
36" x 4-3/4"
58.0
MST 36LE
36" x 8-1/4"
66.0
Other sizes available on request.
No.
Size
Wt/Ctn (lbs)
CFT 6SEP
6" x 4-3/4"
24.0
CFT 8SEP
8" x 4-3/4
26.0
CFT 10SEP
10" x 4-3/4"
28.0
CFT 12SEP
12" x 4-3/4"
31.0
CFT 6LEP
6" x 8-1/4"
32.0
CFT 8LEP
8" x 8-1/4"
34.0
CFT 10LEP
10" x 8-1/4"
37.0
CFT 12LEP
12" x 8-1/4"
39.0
Other sizes available on request.
No.
Diameter Size
Length Wt (lbs)
MFG 1CONE
1"
1"
.09
MFG 114CONE
1-1/4"
1-1/2"
.018
SNAPTIES
TIEING/HANDSET
