SD SC64
TIEING/HANDSET
Cone Removal Wrench
This “tee” handled wrench utilizes a lag screw thread for easy
insertion and removal of snaptie cones which failed to remove
themselves along with the tie end.
Concrete Plug
Concrete plugs are designed to be used with 1" x 1" snaptie cones. Break
or twist snap-tie end off the cured wall. Apply with plastic applicator
bottle into void. For a cleaner finish, dip the end of a concrete cone into
the adhesive solution to avoid drips. Then simply push the cone firmly into
the void. Adhesive holds instantly and fully cures within 15 minutes. Sand
flat if protruding.Concrete plugs are preferred over patching due to less
labor and the elimination of possible patch shrinkage.
Wrench Head Socket
The special socket wrench makes form stripping fast and easy.
The socket fits securely over the five sided head. A quick half turn
is all it takes to break the tie. Takes a 3/8" socket wrench.
How to Break Back Wrench Head Ties:
1. Keep the tension on the tie and bracket.
2. Place a 3/8", 5 point socket and ratchet over the
head of the tie.
3. Standing in front of the tie, hold the socket on the
hex head with one hand and turn the ratchet with
the other. A 1/4 to 1/2 turn of the ratchet will normally
break the tie end.
4. Mason's cannot guarantee that ends longer than 4-
3/4" will breakback consistently.
No.
Description Wt (lbs) Qty/Ctn
DS 1CONPL Flush
0.03
500
DS 1CONR Reveal
0.02
2,000
No.
Wt (lbs)
DS 44245
1.0
No.
Wt (lbs)
CFT PW
1.0
SWL provides a factor of safety of approximately 2 to 1.
Snap-Coil
™
Tie
A multipurpose tie for job-built form systems. Standard button head snap tie on one end and a 1/2" coil rod adapter on the other.
Snaps off like normal tie. A low cost solution for one-sided forming and adjustable-length ties. Welded to rigorous standards using
computer-controlled equipment: each tie is as strong as a standard snaptie. Standard 2250 lbs Safe Working Load.
Just like Loop-Coil Ties, Snap-Coil Ties can be used with 1/2" coil rod to make adjustable ties or to anchor into existing walls for one-
sided walls. Here, Snap-Coil Ties are used to form a one-sided, battered wall. The ties are threaded onto 1/2" coil rod stubs welded
onto vertical sections of steel pipes left from previous grouting operation. For about the cost of a single coil tie, the ties give you the
adjustability of a coil tie with the convenience of a disposable snap-tie end. Eliminates the labor and expense of coil bolts or other
removable components.
Supplied with standard 1" cones and 1" breakback. Available in 4-3/4" end (SC-64) or 8-1/4" end (SC-68). Like all Transition Ties, the ties
can also be used for making adjustable-length ties or used with Rebar Hooks for Stay-Form blind side walls and other applications. 100
pieces per carton.
No.
Size
SWL Tension
(lbs)
Min
1 side Wall
Wt (lbs)
SD SC64 4-3/4" end 2,250
6"
.29
SD SC68 8-1/4" end 2,250
6"
.33
¾"
1"
1"
⅜
"
FLUSH
REVEAL
1"
¼
"
½
"
⅜
"
1
"
SNAPTIES
