TIEING/HANDSET
Cast Hex Nut
Coupler
Provides an efficient and safe alternative to conventional
forming of protruding DCR bar. Allows for fast stripping and
works safely by completing the splice of a later time.
Expansion Anchor
Expansion anchors can be used with 5/8" THREADBAR
®
. These anchors
are used in many applications including one sided forming off existing
concrete or temporary tiedowns in existing slabs. The fast Dywidag
thread pattern (2
½
threads per inch) provides quick installation and
stripping. Available in two bore hold diameters 1
⅜
" and 1
½
", simply
determine the estimated compressive strength of existing concrete
and the depth of the hole. Safe Working Load Information available
on request.
No.
Size
SWL Tension (lbs) Wt (lbs)
DSI 58HN 5/8"
10,000
0.30
DSI 78HN 7/8"
10,700
1.10
No.
Size
Wt (lbs)
f
DSI 58EA 5/8"
1.00
No.
Size
Hole Diameter
Wt (lbs)
DSI 58C
5/8"
19,100
1.20
DSI 78C
7/8"
39,200
2.50
SWL provides a factor of safety of approximately 2 to 1.
DYWIDAG THREAD
