Push-Fit Cones
This spreader cone is used with 3/4", class 200 PVC pipe
to allow 5/8" threaded rod to pass through the concrete
untouched.
SWL provides a factor of safety of approximately 2 to 1.
PLASTIC SLEEVE
PLASTIC CONE
BEARING PLATE
THRU TIE
WING NUT
No.
Wt (lbs)
Qty/Ctn
DS 34PF
0.15
500
Threadbar
®
Threadbar is hot-rolled, high strength steel with two
flat sides in the thread pattern that allow gripping
and turning of the bars with a crescent wrench.
The flat sides facilitate self-cleaning with each
stripping operation. Threadbar
®
is bendable around
a 6 diameter pin.
No.
Size
SWL Tension (lbs) Wt/Lf (lbs)
DSI 58TB 5/8"
20,200
1.0
DSI 78TB 7/8"
35,900
1.7
1/2"
1-3/4" OD
3/4" ID
DCR Bar
The DCR is manufactured from high strength steel and fully
threaded. DCR bar is considered more ductile than standard
coil rod. DCR Bar is bendable around a 6 diameter pin and
is also weldable allowing its use for welded waterstop. DCR
bars provide a very economical solution for conventional
and special tying/anchoring application. All hardware is
interchangeable with thread bar.
No.
Size
SWL Tension (lbs) Wt/Lf (lbs)
DSI 58DCR
5/8"
19,100
1.0
DSI 78DCR
7/8"
30,900
1.7
DYWIDAG THREAD
TIEING/HANDSET
