TIEING/HANDSET
Clip On Waterstop
Easy placement. Can be attached before or after the snaptie is
installed. One touch attaachment. Expands by water contact.
Fixed Metal Washer (FW)
Fixed metal washers are available in standard capacity.
Breakback of fixed washer is 1/4". 1-3/16" end uses 3/4"
plywood and wedge. 1-5/8" end uses 1-1/8" plywood
and wedge. Fixed Metal Washers provide a safe working
load of 2,250 lbs. Adequate end clamps are required to
develop safe working load. 100 pieces per carton.
Vinyl Sleeve
1/2" diameter x 2" long vinyl plastic sleeve, nominal 1"
breakback. For use with formliner. The length of the sleeve
seals against leakage and also leaves a smaller hole after
stripping to be patched. Provide a safe working load of
2,250 lbs. Adequate end clamps are required to develop
safe working load.
Available on request.
SWL provides a factor of safety of approximately 2 to 1.
Heavy Duty
Heavy Duty Snapties are manufactured from high carbon
wire with a 1 x 1 plastic spreader cones providing a
nominal 1" breakback. Available in long and short end,
special ends available upon request. Heavy Snapties
provide a safe working load of 3,125 lbs. Adequate end
clamps are required to develop safe working loads.
Available on request.
Custom Manufacturing
Masons own manufacturing capabilities allow fast
availability of any snaptie up to 144" overall length.
Special sizes for battered walls and different ends to allow
different forming methods on each side fo the wall. Can
be furnished without cones for pass through ties.
For special requirements give us a call.
WALL THICKNESS
BREAKBACK
LUMBER
AND
WEDGE
LUMBER
AND
WEDGE
No.
Size
Wt/Ctn (lbs)
CT 61316FW
6" x 1-3/16"
18.0
CT 81316FW
8" x 1-3/16"
21.0
CT 101316FW
10" x 1-3/16"
23.0
CT 121316FW
12" x 1-3/16"
26.0
CT 6158FW
6" x 1-5/8"
19.0
CT 8158FW
8" x 1-5/8"
22.0
CT 10158FW
10" x 1-5/8"
27.0
CT 12158FW
12" x 1-5/8"
32.0
Other sizes available on request.
No.
Wt/Ctn (lbs)
ADE CRING8 .015
