TILT-UP/PRECAST
TILT-UP
Gyro Tilt Plus Hardware
The Gyro Tilt Plus is the natural, evolutionary
development of the parent Gyro Lift
System. The addition of a simple ground
release capability to the long list of design
features of the parent system makes Gyro
Tilt Plus an extremely versatile lifting system.
The Gyro Tilt Plus System's expanded
capabilities are nicely suited to tilt-up
concrete construction. It's ease of use
makes the erection and handling of tilt-up
panels quick, safe and cost effective.
Gyro Tilt Plus Insert
The GTP Insert is a ¾" diameter insert manufactured
from high quality steel. The hot forged spherical head is
engaged by the system hardware. The insert assembly is
complete with a plastic void and plastic-protected wire
base. The insert assembly is easily positioned and tied to
the rebar mat and requires no special orientation.
FACE LIFT APPLICATION
No.
Wt/Ctn (lbs)
RC 10013 13.5
No.
Size
Wt (lbs)
RC GP5 5"
1.60
RC GP512 5½"
1.65
RC GP6 6"
1.70
RC GP612 6½"
1.75
RC GP7 7"
1.80
RC GP714 7¼"
1.83
RC GP712 7½"
1.85
RC GP8 8"
1.90
RC GP812 8½"
2.53
RC GP9 9"
2.56
