TILT-UP/PRECAST
Slab Saver II
A patented product manufactured from durable polypropylene,
molded into a "T" section with stem. The purpose of Slab Saver is
to eliminate the scarring and damage of the concrete at time of
lifting a tilt-up panel. After edge forms are put in place, a 2' piece
of Slab Saver is put into each bottom corner of the panel and
nailed into place. Concrete is poured, vibrated and consolidated
around the stem of the Slab Saver. Nails are pulled and forms are
removed. Slab savers are made from durable PVC and will not
scratch your floors. They are easy to install and will help reduce
your installation costs.
Rustication - PVC Rigid
Rustications are made of durable PVC used for the addition of
rustication bands in concrete. Incorporated in the patent pending
design is a double 45° chamfer for a smooth concrete edge and
concealed fasteners. Clean area where product is to be installed
to allow the product to seal tightly against the casting surface. To
install, place base clip down on casting surface and install fasteners
at 16 to 24 inches on center. The base clip has been designed
with a "V" groove to position the fastener or drill bit in the center
of the clip. It is important the fastener head does not exceed a
height 3/16" above the finish surface of the clip base. Once the clip
base is securely fastened to the casting surface, place the Tru-Line
rustication piece over the base clip, aligning the grooved tabs into
the base clip. Apply pressure down vertically over the center of
the Rustication, working from one end the other, until it locks into
position. Since the Rustication is made of a smooth plastic, there
is no need for form coating or oiling of the plastic, though oil may
provide an easier release. Concrete can be placed directly on the
surface, though care should be taken when concrete is pumped
to place concrete directly over the center of the piece. Standard
length is 8'. Additional base clips are available in 8'-0" lengths.
Concrete nail
Slab saver
Concrete
Form
No.
Size
Qty/Ctn
Wt/Ctn (lbs)
PS 734
24"
42
38.0
No.
Width "A"
Height "B"
Chamfer Angle Pieces per Box Wt/Ctn (lbs)
Standard Profile
PS 712
2-1/2"
¾"
45°
12
18.0
PS 713
3½"
¾"
45°
20
45.0
No.
Std. Lengths
Pieces per Box Wt/Ctn (lbs)
Base Clip II
PS 744
8'
60
25.0
No.
Description
Size
Chamfer Angle Pieces/Ctn
Wt/Ctn (lbs)
PS 765
Hanging Chamfer ¾" x 8'
45°
42
42.0
Width "A"
Rustication
Height
"B"
Base Clip
Flex Edge Seal
Base Clip
Chamfer
Rustication
Pre-Mitered
End Piece
Flex Edge Seal
HANGING SINGLE CHAMFER
45°
B
