TILT-UP/PRECAST
TILT-UP
Drill-In Lift Plate
For use in Tilt-up panels when lifting inserts cannot be
located. Consult Masons for technical information.
Stripping Bar
This all purpose is a heavy duty tool that has many uses
on any jobsite, from stripping forms to jockeying tilt-up
panels. The handle is fabricated from 1 x 2 tubular
steel which is carefully mig-welded to a heat-treated
milled blade.
Form Angle
The Form Angle (shelf bracket) is used for tilt-up perimeter
forming is fabricated from 18 gauge galvanized steel which
allows for numerous re-uses. The two sizes of holes permit
various attachment methods. Used to fasten the angle to
the floor slab and form lumber. Suggested spacing is 2'-0" on
center when using 2x lumber as edge forms. 50 pcs per carton.
No.
Size
Wt (lbs)
TBS S
3" blade width x 57"
14.0
Stripping Bar Junior
TBS SJ
46"
12.0
No.
Description Wt (lbs)
DS 10052
Panic Plate 33.0
No.
Size
Wt (lbs)
CT CF6
7/8" x 5-3/16" x 6-15/16"
1.0
Saw Cut Cover
This saw cut cover combines rigid and flexible
PVC. This combination of materials provides a
faster, easier method for temporarily sealing and
protecting saw cut joints in your slab. Its rigid
structure makes it easy to install compared to all
flexible products. Its flexible fins ensure a
secure fit
in imperfect saw cuts, and a tighter seal against
the slab than with all rigid products.
No.
Length
Wt (lbs)
Qty/Ctn
PS SCC
8' - 0"
0.22
100
Unique Low-Profile Design
