TILT-UP/PRECAST
TILT-UP
Dry Film Lubricant
For proper reuse of the COIL ANCHOR, dip the threaded
portion of the bolt into our liquid DRY FILM LUBRICANT
and immediately shake off any excess lubricant. Set the
lubricated bolt aside and allow the lubricant to dry. Thread
the new tang onto the bolt so the flattened end of the tang
points towards the head of the bolt. The tang should be
assembled onto the bolt with only a light finger tightness,
NO MORE than 1½ turns, making certain that you DO NOT
pre-expand the tang.
Coil Anchor
Insert the assembled COIL ANCHOR through the foot plate
of the pipe brace into a properly drilled hole. Tap the COIL
ANCHOR bolt all the way into the hole so that the washer
and bolt head rests on the foot plate of the brace.
T-13-G Thread Gauge
T-13-G Thread Gauges are recommended to check T-13 bolt
thread wear when reusing T-13 Coil-Anchor Bolts.
No.
Description
Wt (lbs)
Qty/Ctn
DS 49206
3/4"x4-1/2"
.80
20 sets
DS 123045 3/4"x6"
1.0
20 sets
DS 49203
Tang only
.04
100
No.
Wt (lbs)
DS TI7HD
5.0
Knee Brace Bracket
Stiffens and increases the safe working load of B-8, B-9,
and B-10 jumbo braces. Eliminates need for lateral and
end bracing. Adjustable tripod legs allow the brace to be
secured to various structural geometrics.
No.
Wt (lbs)
No.
Size
Wt (lbs)
DS 49205
6 oz
0.40
WASHER
4 TURN TANG
.740"
MAXIMUM
TANG O.D.
ANCHOR
