TILT-UP/PRECAST
P-54 Disposable Recess Plug
Available in two sizes; 9/16" or 3/4" anchor shaft diameter. Provides void clearance in
concrete for lifting eye. Built in tabs hold and locate preformed shear bar in proper
location. Made from high density polyethylene. Two halfs snaps easily around head of
Swift LIft Anchor. Designed for use only with P-59 smooth wire shear bar, DO NOT USE
with rebar type shear bars.
No.
Size
DS 60725
2 Ton
DS 60728
4 Ton
P-56 PL Recess Plug
The P-56-PL Swift Lift Plus Recess Plug is manufactured from high-grade elastomeric,
thermal set urethane to provide improved tear, heat and chemical resistance. The
versatile, reusable plug utilizes a variety of accessories to provide installation and
stripping ease in many different applications. P-56-PL recess plugs are available for
1, 2, 4 and 8-ton system sizes.
P-59 Shear Bar
When edge lifting thin precast wall panels from flat to vertical, the P-59 shear bar is
used to transfer the applied shear load deeper into the panel. In order for the shear
bar to work properly, it must be secured tightly against the recess plug.
P-67 Stud Plate
Available with 5/16"-18 NC threads for use with 1 ton recess plugs and 7/16"-14 NC
threads for use with all other P-55 Recess Plugs.
No.
Size
Wt (lbs)
DS 60721
1 Ton
0.18
DS P56PL2
2 Ton
0.35
DS P56PL4
4 Ton
0.68
DS 60730
8 Ton
1.00
No.
Size
Description
Wt (lbs)
DS 60116
8 Ton
#6 Rebar
4.38
DS 60132
2 Ton
.375 Smooth Rod 0.94
DS 60134
4 Ton
.440 Smooth Rod 1.50
No.
Size
Wt (lbs)
DS P67PL2
3/8" x 3" 2 Ton .23
DS P67PL4
3/8" x 3" 4 Ton .28
DS P67PL8
3/8" x 3" 8 Ton .30
P-64 PL Wing Nut
This nut is available in two different thread sizes. The 5/16"-18 NC threaded wing nut is
designed for use with the 1 ton P-63 SL Stud while the 7/16"-14 NC threaded unit works
with the 2,4 and 8 ton studs
No.
Size
DS 103410
3/8", 2, 4, 8 tons
SMOOTH SHEAR BAR
PRECAST
