TILT-UP/PRECAST
P-98-S Shear Bar
P-98-S Shear Bars are designed specifically to fit fleet lift erection
anchors. The P-98-S Shear Bar will work with the erection anchor
to achieve the highest shear capability. Shear Bars are available
in plain finish, hot dipped galvanized or epoxy coating. Shear
Bars are available in 2, 4, and 8 ton sizes.
P-100
SWL provides a factor of safety of approximately 4 to 1 in 3,500 psi normal weight concrete.
Consult manufacturers data on values on shear and reduced edge distance.
P-102 Steel Wedge:
P-103 Foam:
P-102
P-103
No.
Size
Wt (lbs)
DS FL140
2 Ton
0.98
DS FL141
4 Ton
1.07
DS FL142
8 Ton
1.23
No.
Recess Load Range Wt (lbs)
FL 017
2 Ton
0.13
FL 084
4 Ton
0.38
FL 085
8 Ton
0.94
No.
Anchor Load Range Unit/Pkg Wt/Pkg (lbs)
FL 087 1 & 2 ton
1,000
5.00
FL 069 3 & 4 ton
1,000
5.00
FL 091 6 & 8 ton
500
10.00
P-101
No.
Size
Wt (lbs)
P-100
DS FL160
2 ton
0.14
DS FL144
4 ton
0.24
DS FL111
8 ton
0.58
P-101
DS FL131
3/8"x7"
0.24
Holding Plate and Rod
PRECAST
