TILT-UP/PRECAST
PRECAST
P-50 Swift Lift Universal Lifting Eye
Uni-Lift Hardware is specially designed with a "T" shaped slot that hooks under the anchor head. The bail is a solid steel plate with
a large hole to attach a cable clevis. The bail rotates from front to back in the lifting body. This action is an advantage over other
existing systems as rigging does not need to be reversed when rotating a panel up and down. Has approximately a 5:1 safety factor.
Under no circumstances should user modify, apply heat, weld or grind any part of the lifting hardware.
P-52 Swift Lift Anchor
The P-52 Swift Lift Anchor is hot forged from carbon steel. The formed head provides spherical seating that the Lifting Eye engages,
while a disc-shaped fott is embedded in the concrete. Due to its being forged part, the Swift Lift Anchor does not depend on welds
or thread engagement to develop its safe working load. Forging provides maximum safety with its advantageous material structure.
This allows anchor to easily meet the OSHA requirement of a 4 to 1 factor of safety.
No.
Anchor Size
Ton x Length
SWL (tons)
Wt (lbs)
DS 60596
3/8 X 4-3/4
1 Ton
0.19
DS 60663
9/16 X 3-3/8
1.4 Ton Galvanized 0.32
DS 126866
9/16 X 6-3/4
2 Ton Galvanized 0.55
DS 60673
3/4 X 4-3/4
2.9 Ton Galvanized 0.97
DS 60675
3/4 X 9-1/2
4 Ton Galvanized 1.58
DS 60679
1-3/16 x 13-3/8 8 Ton Galvanized 4.61
Other sizes available on request.
No.
Size (Tons)
Wt (lbs)
DS 60571
1-1.3 T
3.0
DS 60574
1.5-2.5 T
5.0
DS 60577
3.0-5.0 T
7.5
DS 60580
6.0-10.0 T
17.0
DS 60583
20.0 T
35.0
SWL provides a factor of safety of approximately 5 to 1.
L
Swift Lift System
The Swift Lift (SL) System is a quick connect-disconnect system which allows precast concrete units to be handled repeatedly with
speed, safety and economy. The system is a non-welded system and also avoids threaded connections, which are time-consuming,
subject to thread wear and damage, and the further risk of not being fully engaged, with consequent reduction of the safe working
load. The reusable SL Lifting Eye is free of these disadvantages and by virtue of its quality and heavy duty construction will give
years of use. The Swift Lift System is available with safe load ratings of 1, 1.3, 2, 2.5, 4, 5, 8, 10, and 20 tons. Each component is clearly
marked in tons with the maximum safe rating load. The system is extremely versatile in use, being suitable for vertical pull or diagonal
pull. It can also be used to raise concrete units from the horizontal to the vertical position without the aid of a tilting table.
