TILT-UP/PRECAST
P-94-S Fleet Lift S-Anchor 6-Ton
The P-94-S Fleet-Lift S-Anchor is a high strength, hot forged anchor
that can be "wet set" or used with the optional T-41 Plastic base
in face-lift applications. When the P-94-S anchor is used with the
Fleet-Lift high capacity ring clutches, safe working loads up to
12,000 pounds can be realized.
No.
Size SWL Tension
Wt (lbs)
DS FL501
3-1/8"
3,900
DS FL502
3-7/8"
5,000
DS FL503
4-1/8"
5,370
DS FL505
4-7/8"
6560
DS FL506
5-1/8"
6970
DS FL509
5-7/8"
8250
DS FL510
6-1/8"
8700
DS FL513
6-7/8"
10070
DS FL515
7-7/8"
12000
SWL provides a factor of safety of approximately 4 to 1 in 3,500 psi normal weight concrete.
Consult manufacturers data on values on shear and reduced edge distance.
P-92-FEW Fleet Lift Forged Erection Anchor
Ideal for horizontal to vertical edge lifts and the shear
rotation of thin-walled units. It has a specially designed
head to provide added protection against spalling. The
specially designed body allows for full reinforcement.
Because the concrete forms in the newly designed slot,
the anchor develops a shear cone at the bottom of the
slot opening.
No.
Size
Wt (lbs)
DS 127619 3T
DS 127615 6T
DS 127616 10T
