Mega Shore Support System
The MEGA SHORE Support System
is designed to decrease labor costs, improve
safety and meet the demands of structural requirements. The system has been
designed to combine maximum flexibility in use with a minimum number of
components. Leg's, frames, and beams are the only 3 components used for basic
application. Mega Shore can support loads up to 22,000 lbs per leg. Legs are
available in three sizes, each with continuous vertical slots to allow ledger frames
to be fitted at the optimum height. Screw jacks can be fitted top and bottom for
vertical adjustment up to 8 feet.
All ledger frames are made of aluminum. The outside tube is 1.9", so you can use
standard working platforms. Ledger frames can be removed or inserted in any
location while the system is fully erected.
Mega Shore is particularly well suited for heavy bridge supports. With the flexible
design capabilities of Mega Shore, large sections can be easily moved. With high
slabs, the advantages of the Mega Shore System are apparent. With extremely
high load capacities, you will require less equipment. This results in fast and efficient
erection and dismantling.
Flying Table
Size 2
Size 4
Size 6
Legs Min.
Length * Wt (lbs)
Size 2 5' 7"
39.7
Size 4 9' 6"
50.7
Size 6 14' 1"
63.9
* Including Jack
Legs are available in three sizes,
each with continuous vertical
slots to allow ledger frames to
be fitted at the optimum height.
Titan screw jacks can be fitted
at the optimum height. Mega
Shore screw jacks can be fitted
top and bottom for vertical
adjustment up to 8 feet.
5'7" - 9'6" (1700-2900 mm)
5'11" - 13'5" (1800-4100 mm)
11'2" - 19' (3400-5800 mm)
9'6" - 13'5" (2900-4100 mm)
9'10" - 17'5" (3000-5300 mm)
14'1" - 18' (4300-5500 mm)
14'5" - 22' (4400-6700 mm)
HORIZ. FORMING & SHORING
MEGA SHORE
