HORIZ. FORMING & SHORING
DeckFast™
, formerly Topec™ Deck System, is a
modular slab formwork system that is used for
commercial and industrial applications. The system
will support slabs up to 22" and heights up to 19'
above the floor or ground.
The basic DeckFast system consists of tubular post
shores that are adjustable to 18', bearing supports
and modular forming panels. The uniqueness of
this system lies with bearing supports that capture
and support corner clusters of four panels. When
the bearing supports are fastened to flat top post
shores, the panels and post shores can be erected
individually from below, simplifying the erection
process.
The easy-to-use DeckFast system, with two basic
components and two support rods, can be erected
with a minimal amount of training. Even workers
who are not familiar with the system can achieve
high production rates per worker per day. Even infill
sections can be easily formed and economically
installed using DeckFast components. Forming panels
are made from 5-ply bonded veneers with 10 mm
plywood. Edges are protected by specially designed
powder-coated aluminum framing members that not
only minimize the gap between panels but also add
to panel strength. Powder-coated aluminum frames
minimize maintenance cleaning efforts and reduce
cleanup costs.
Standard DeckFast Panel size is a nominal 5.9' x 5.9'
(34.8 ft²) but weighs only about 100 lbs. Other sizes are
also available to fit your needs.
Typical Application
Guardrail Post
Corner Panel
90/90 Panel
180/180 Panel
180/90 Panel
Transverse Beam
Adjustment Beam
Adjustment Panel
Bearing
Edge Support
Erection Rod
DECKFAST™
